IEC 60335 /IEC 60601 Ball Pressure Tester For Heat Resistance of Non-metallic Materials
- Shenzhen
- T/T
- 2 days
You May Like
-
IEC61032 Figure 12 8.6mm Jointed Children Finger Probe 18
-
IEC61032 Figure 13 5.6mm Children Joint Finger Probe 19
-
IEC61032 Figure7 ?12 mm Jointless Rigid Finger Probe 11
-
IEC60065, IEC61032 Rigid Finger Probe 11 With 0-75N Force
-
IEC/EN 60335 Access Probe 11 With Force Scale From 0-50 N
-
IEC/EN 60335-1 Figure 7 with 0-50N Force test Fingernail
Product Details
| Brand Name | JUSDATEST | Place of Origin | China | |
| Model Number | JSD-BP |
Product Description
Overview
This device is designed and manufactured according to the IEC60335、IEC61010 standards clauses of the ball pressure test, and is a special instrument used to test the heat resistance of non-metallic materials. It is suitable for heat resistance test of non-metallic materials such as electrical equipment and its components and parts, non-ceramic solid electrical insulating materials.
Technical Parameter
Loadweight | 20N±0.2N | Sphere | R2.5mm |
Material | 304 stainless steel | Pillar | Ф50X100 Ф2.5X25 |
Standard | IEC60335、IEC60601、IEC60950、IEC61010 | ||
Balance check:
Put the pressure ball on the support, adjust the position of the load body according to its swing, then tighten the load body, put the pressure ball on the support again, and observe its swing to determine the adjustment effect. Only in the case of balance, the pressure ball can be placed smoothly, otherwise the pressure ball will swing obviously, if it is detected by optical equipment, it will seriously affect the accuracy of the test results.
