Titanium Carbide Tic Particle Used for Powder Metallurgy Production Metal Ceramic

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

FEATURES AT A GLANCE

Product Introduction

Titanium carbide,Chemical formula TiC,Molecular weight 59.91,Carbon content 20.05%,Density 4.93g/cm3, Melting point:3160ºC,Boiling point 4300ºC.Titanium carbide is offwhite powder with cubic system structure of NaCl type.The carbide is mainly used in preparation of cermet,heatresistant material and cemented carbide due to its high melting point ,hardness and chemical stability. The wearresistance,corrosion resistantce and resistance to oxidation of hard alloy can be improved clearly when TiC(6~30%)is mixed in WC-Co cemented carbide and from TiC WC solid solution with WC.It is more suitable to process steel products.Also we can produce cemented carbide without tungsten using Ni-Co alloy to enhance the cutting speed and precision and smoothness of processed component.

Product Application

Titanium carbide is the typical transition metal carbide. Its key is by the ionic bond, the covalent bond and the metallic bond mix in the identical crystal structure, therefore titanium carbide has many unique performance. The crystal structure had decided the carbonized titanium has the high degree of hardness, the high MP, the wearability as well as conductive and so on essential feature. The carbonized titanium ceramics are the titanium, the zirconium, in the chromium transition metal carbide develop the broadest material. From the carbonized titanium's have conducted the extensive research powder body, the block body to the thin film. In the aluminum oxide flinty dispersed phase composition turns round in the material, turns round ceramics' effect as well take the aluminum oxide - carbonization titanium, the carbonized titanium may suppress when the agglutination aluminum oxide crystal grain growing up, hindrance fracture growth; The carbonized titanium has the good wettability with certain metals, the carbonized titanium ceramics develops quickly, the carbonized titanium is in the metal-based compound materials important intensifier, its product in the machinery, electronic,chemical, the environmental protection, the fusion reactor, the defense industry and so on many domains obtains the widespread application.Titanium carbide may also with the tungsten carbide, the tantalum carbide, the carbonized niobium, the chromic carbide, the titanium nitrides form dual, three Yuan, the quaternary compound solid solutions, applies in the spray coating material, the welding material, the flinty membranous material, the military aviation material, the hard alloy and the cermet.

Physical and mechanical properties

Medium/Fine Grain Size
Grade	Chemical Contents(%)											Chemical Contents(%)	FSSS Fisher Number (um)
		Total Carbon (T.C.)	Free Carbon (F.C.)	Impurity Contents(<=%)
		Total Carbon (T.C.)	Free Carbon (F.C.)			Si	Al	O	N	Na	Ca
TiC-X	>=19.0	<=0.40	0.05	0.01	1.2	0.5	0.01	0.02	<=1.5
TiC-1	>=19.0	<=0.40	0.05	0.01	0.5	0.6	0.01	0.02	<=2.0
TiC-2	>=19.0	<=0.35	0.05	0.01	0.4	0.5	0.01	0.02	2.0-4.0

Coarse Grain Size

Grade

Chemical Contents(%)

Total Carbon

Free Carbon

Impurity Contents(<=%)

(T.C.)

(F.C.)

Co+Ni

TiC-C

>=19.10

<=0.40

0.25

0.1

0.3

0.5

0.3

0.6

0.1

Note: We can make the different particle size and chemical composition according to customize.

Company Profile

Zhuzhou Hastion High-tech Materials Co., Ltd.(short for HASTION)

is located in Yanling Small and Medium Enterprise Pioneer Park in Zhuzhou City, Hunan Province, which is covering an area of 60,000 square meters and a planned factory area of 50,000 square meters. Now HASTION have 2 different
productions lines, one is the raw material metal compound and elemental powder(TiC/Cr3C2/VC/NbC/ZrC/HfC/(W,Ti)C

/(Ta,Nb)C and so on), the other one is the titanium carbide cermet rod/insert/plate/customized shape/guide roller and so
on(belong to the steel-bonded cemented carbide), until now our products have been sold to many countries, like the Turkey, Belgium, Australia, Japan, Korea, Vietnam, India, Pakistan, Thailand and etc.

Our Workshop

Production Process

Titanium Carbide production
The production process of powder-metallurgical products basically includes the four steps of powder preparation, forming, sintering and finishing.

Titanium carbide production
The APT (ammonium para-tungstate) is calcined into tungsten oxide under high te-mperature. Subsequently the oxide is reduced to tungsten metal in a hydrogen atmosphere. The metal powder is then mixed with carbon and carburised under inert atmosphere at high temperatures. The production parameters are decisive for the WC grain size in the sintered carbide.

Powder preparation
The tungsten carbide is intensely mixed with the binder metal cobalt, nickel or iron, various grain growth inhibitors and materials,which promote compaction, by wet grinding so that a homogeneous suspension is created. Afterwards, the suspension is dried in a spray tower to produce a granulate with good flow characteristics. This granulate represents the basis for all forming processes.

Metal forming
The objective of the forming process is to obtain a near net shape sample. Pressing is normally carried out at room temperature with pressures reaching up to several tons per square centimetre.There are several ways of pressing blanks:During isostatic cold pressing the powder is filled into an elastic flexible hose and pressed into acompacted form through high liquid pressure. The powder blocks which are produced in this way can then be processed mechanically. All common machining methods like milling, cutting, drilling or turning maybe applied.In uniaxial pressing the pressing tool consists of a die and an upper and a lower punch. The carbide powder is filled into the die and then compacted to create the so called green carbide,which is ejected from the pressing die.Extrusion pressing is mainly used to produce rectangular bar or cylindrical rod, with or without axial hole(s). A plasticiser is added to the powder. The resulting paste is pressed through an extrusion nozzle. Before sintering, the plasticiser must be evaporated in special drying furnaces. Metal Injection Moulding (MIM) is a process used to produce more complex forms which cannot be produced by direct pressing. The paste preparation is similar to the extrusion process.

Sintering process
The sintering process converts the blank into a homogeneous and dense carbide with a high level of hardness. The material is sintered at temperatures between 1,300 and 1,500 °C (liquid phase sintering) and sometimes also at high pressure (up to 100 bar). The volume is reduced by up to 50 % during this process.

Finishing
In order to achieve the final requirements of surface finish, tolerances,etc. carbide parts can be subjected to a series of finishing processes such as grinding, spark erosion and coating.

Product packaging

Exhibition

Vietnam International Industrial Fair

Shanghai International cemented carbide Fair

Certifications

FAQ

Q1. Are you factory or trading company ?
A: We are the largest manufacturer of TiC rod with 50000m2 factory in China, and the lowest competitive price for you as the
mainly raw material of TiC rod(TiC powder) is produced by ourselves. Warmly welcome to visit our factory. CONTACT US NOW.

Q2. What's the MOQ ?
A: (1) NO MOQ if stock available.
(2) If no stock,different products different MOQ, and final quantity can be negotiated .
So email or call me what's the products you interested in ?

Q3. What is your principle for the samples ?
A: FREE SAMPLES(<1kg) for you if you are willing to pay the shipping cost.

Q4. Which payment can be acceptable ?
A: By T/T, L/C, Western Union, Paypal and so on.

Q5. How about your delivery time?
A: Normally it's 7-15days after receipt of deposit. Large quantity needs to be negotiated.
