Outdoor Exterior Aluminium Stacking Bifold Accordion Folding Sliding Door Panoramic Patio Door Slide Turn Door System
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Miami Dade Approved Best Sound Proof Big Folding Glass Doors Dp50 System
-
Grey Aluminum Large Folding Glass Front Doors for Inside Home
-
Aluminum Frame Slim Folding Door Slimline Aluminium Bi-fold Doors For Residential
-
Exterior Aluminium Swing Bi-folding Door Sliding Turn Pivot & Stacking Door Panoramic Patio Door
-
Hurricane Impact Patio Bifold Doors / Soundproof 2 Panel Aluminium Folding Doors For Exterior Entrance
-
Slide And Swing Wave Folding Stacking Pivot Panoramic Glass Door System
Product Description
Product Description
Glass Standard | Comply with AS2208 / IGCC / CE / ISO | ||||||
Standard/Certificate | Comply with CE / ISO | ||||||
Thermal Insulation | U value from 1.5 to 2.0 W/M2k | ||||||
Window Rating | N6 | ||||||
Sample lead time | 7 days | ||||||
Water penetration | 600 pa | ||||||
Ultimate strength | 4500pa | ||||||
Air infiltration | 75/150 | ||||||
Extrusion alloy | 6063-T5 profile with 2.0-3.0 mm thickness for door | ||||||
Hardware | German brand with 10 year warranty | ||||||
Surface treatment | Powder coated color | ||||||
Packing | Wooden or Carton Box with Bubble Bag, Clear film,Foam inside. | ||||||
Delivery | 15-35 Days after order confirmed | ||||||
Key Features
● High quality extruded aluminum for strength & performance
● Ideal for hot & cold climates.
● Master swing door on every system
● Unlimited width system
● In swing or out swing
● Up to 10′ tall
● Panel width of 20″ to 40″
● Interlocking tongue-n-groove for superior seal and security
● Concealed multi-point locking system for ease of operation and security
● Robust panels suitable for all environments
● Thermal core for reduced thermal transfer
● Add a screen system for year-round comfort and protection
Details Images
Active Main Door
Every Panoramic folding patio door comes with a main swing door at one end. This door serves as the primary access in and out. As most of the time, you will be using your door with the rest of the panels in the secured position having the main swing door is both convenient and practical.
Bottom Track Operation
Avoid major header construction with our bottom track supported system. Traditional bi-fold patio doors stress your top support beam with hundreds or thousands of pounds of weight. This added weight often requires a completely new header to be installed. Not so with a Panoramic Door.
Variable Panel Placement
Our aluminum folding doors are equipped with independently operating panels, you can move them to the optimal position to suit your needs at the moment. You can move them all together, or space them out over the span of the opening to manage airflow.
Clean and Elegant
It was important to us that our doors be modern in both design and look. By hiding all the locks and hinges inside the panels and frame, we can offer a clean and elegant door system. And, unlike hinged bifold doors, the Panoramic folding patio door does not require shoot bolts and pull handles.
Patented Hardware
Our patented hardware utilizes permanent magnetic attraction to allow the sliding panel to pivot open. This unique design is the secret to the way the Panoramic folding patio door operates and why we call it a “slide-and-pivot” patio door.
Interlocking Panels
A second patented feature of the Panoramic Door system is the tongue-and-groove interlock between the slide and fold panels. The tongue-and-groove delivers a superior security and weather rating.
Weather Rated or Flush Track Options
Choose from a variety of track options according to your weather and design needs. Recess your track for a smooth transition from inside to outside.
Thermally Efficient
Energy efficiency is important. A combination of aluminum and PVC makes it possible to build a stronger, more thermally efficient door system that is suitable for all weather conditions.
Handle rebound system
Equipped with handle rebound system, the handle is stable and does not fall down.
The handle can be positioned at 90 degree and automatically bounced back within 45 degree.
Lock body
Multi-point lock system.
Locking is more balanced and protection is more safe.
Cylinder lock system
Made of pure cooper. the switch is smooth and the wave and twist are optional.
Company Profile
Founded in 2010,Foshan Puertana building materials Co.,Ltd. is a modernized enterprise that specializes in high-end aluminum alloy doors&windows,solid interior frosted glass doors,sunrooms and shower rooms etc, integrating R&D,manufacturing,sales and service.It covers 30,000 square meters, and has over 500 staffs.
We are One Stop Building Materials Supplier , we mainly working with the Housing Builder, Developer, Contractor and individul houses , most of our customers from North America , Europe , Australia , and our products can meet the local Building Code.
Our Advantages
Pre-sales service
• 24 Hours Online Consultant. • Sample Support.
• Free Pick-up At Hotel / Airport To Visit Factory.
• Quick & Professional Response To Quotation Request And Technical Question.
Production period service
• Shop Drawing Submitted To Double Check Details.
• Quality Inspection Report Submitted. • Logistics Service Support.
• Installation Solution Provided.
After-sales service
• Providing The Installation Guide And Solution.
• 10 Years Quality Guarantee.
• Any Quality Problem Replace Freely.
Certifications
Project Gallery
Product packaging
FAQ
Q: Are you a factory?
A: Yes. We are factory.
Q: What's your payment term?
A: T/T 30% deposit, full balance against delivery
Q: Can you help with delivery?
A: Yes, we can do FOB, CFR, CIF, DDU.
Q: What's your period of production time?
A: Normally it's 25-30 days. It's negotiable.
Q: Will you check the products' quality before delivery?
A: Yes, we have QC department so we can make products 100% good for you.
Q: What color can you do for the products?
A: We have standard colors for every product. But we can customize it for you.
