Home > Products > HYDRAULICS - PNEUMATICS > grundfos NBG 65-40-200/188 AAF2BESBQQEMW1
grundfos NBG 65-40-200/188 AAF2BESBQQEMW1
USD $1 - $2224
/ Bag
1 Bag(Min.Order)
- 444 Piece / Pieces per Month
- SHENZHEN
- T/T L/C D/P D/A Credit Card PayPal Cash Escrow Other
- 7 days
You May Like
-
Grundfos CR10-07 A-FJ-A-E-HQQE 3x400D 50 HZ
-
Grundfos CR 5-36 A-FGJ-A-E-HQQE No. 96513394
-
AVENTICS Pneumatics Emerson Cylinders Actuators
-
AVENTICS 3/2 directional valve electrically operated AS1 BOSCH SOV R412014669
-
AVENTICS Tie rod cylinder, CNOMO NFE 49 – 001, Series C12P – R422715121
-
AVENTICS Precision pressure regulator, Series PR1 – RGP – R412010259
Product Details
| Brand Name | grundfos | Place of Origin | Brazil | |
| Model Number | NBG 65-40-200/188 AAF2BESBQQEMW1 | Application | Maritime | |
| Fuel | Other | Power | Electric | |
| Usage | Air Pump | Theory | Other | |
| Standard or Nonstandard | Other | Structure | Diaphragm Pump | |
| Pressure | Low Pressure |
Product Description
| Product name | NBG 65-40-200/188 AAF2BESBQQEMW1 |
| Product No | 96703916 |
| EAN number | 5700837567305 |
Technical
| Pump speed on which pump data are based | 2920 rpm |
| Rated flow | 48.33 m3/h |
| Rated head | 36.09 m |
| Actual impeller diameter | 188 mm |
| Nominal impeller diameter | 200 |
| Shaft seal arrangement | Single |
| Shaft diameter | 24 mm |
| Code for shaft seal | BQQE |
| Curve tolerance | ISO9906:2012 3B2 |
| Pump version | A |
| Bearing design | Standard |
Materials
| Pump housing | Cast iron |
| EN-GJL-250 | |
| ASTM class 35 | |
| Wear ring | Brass |
| Impeller | Brass |
| CuZn37Pb | |
| Internal pump house coating | CED |
| Material code | B |
| Code for rubber | E |
| Shaft | Stainless steel |
| EN 1.4301 | |
| AISI 304 |
| t max amb | 40 °C |
| Maximum operating pressure | 16 bar |
| Pipe connection standard | EN 1092-2 |
| Size of inlet connection | DN 65 |
| Size of outlet connection | DN 40 |
| Pressure rating for connection | PN 16 |
| Bearing lubrication | Grease |
| Pump housing with feet | Yes |
| Support block (Yes/No) | N |
| Connect code | F2 |
Installation
| Minimum efficiency index, MEI ≥: | 0.65 | |
| Net weight: | 118 kg | |
| Gross weight: | 135 kg | |
| Shipping volume: | 0.315 m3 | |
| Country of origin: | SG | |
| Custom tariff no.: | 84137011 |
