SAE 100 R12 Steel Wire Spiraled Hydraulic Hose
- T/T Credit Card PayPal
You May Like
Product Details
| Brand Name | Hongxiang | Place of Origin | China | |
| Model Number | SAE 100 R12 |
Product Description
High pressure steel wire spiral hose is mainly used in high-pressure working conditions, and is often used to transport hydraulic fluids such as hydraulic oil, lubricating oil, emulsion, glycol and water.
This high pressure steel wire spiral hose consists of three parts: an inner tube made of oil-resistant, wear-resistant, corrosion-resistant synthetic rubber, reinforcement layer composed of four layers of high tensile steel wire and an outer cover made of synthetic rubber. SAE 100 R12 Wire Spiral Hydraulic Hose works well in high pressure environments. The spiral rubber hose works well when supplying oil-based hydraulic fluid. The hose is made of high-quality synthetic rubber, which is wear-resistant, corrosion-resistant, weather-resistant, ozone-resistant and cutting-resistant, aging and sunlight resistant.
Applicable Specification：SAE 100 R12
Working temperature: -40 °C to +100 °C; (-40 °F to +212 °F).
| Inside Diameter(ID) | Reinforcement Diameter (RD) | Outside Diameter (OD) | Max Working Pressure | Min Burst Pressure | Bend Radius | Weight | |||||||
| DN | inch | mm | mm | mm | bar | psi | bar | psi | mm | Kg/mt | |||
| -06 | 3/8 " | 9.5 | 17.5 | 20.4 | 280 | 4060 | 1120 | 16240 | 125 | 0.69 | |||
| -08 | 1/2 " | 12.7 | 21.1 | 23.9 | 280 | 4060 | 1120 | 16240 | 180 | 0.86 | |||
| -10 | 5/8 " | 15.9 | 24.8 | 27.6 | 280 | 4060 | 1120 | 16240 | 200 | 1.02 | |||
| -12 | 3/4 " | 19.1 | 28.1 | 31.0 | 280 | 4060 | 1120 | 16240 | 240 | 1.23 | |||
| -16 | 1 " | 25.4 | 35.4 | 38.6 | 280 | 4060 | 1120 | 16240 | 340 | 1.91 | |||
| -20 | 1-1/4 " | 31.8 | 43.9 | 47.8 | 210 | 3045 | 840 | 12180 | 420 | 2.56 | |||
| -24 | 1-1/2 " | 38.1 | 50.4 | 54.0 | 175 | 2538 | 700 | 10152 | 500 | 2.97 | |||
| -32 | 2 " | 50.8 | 63.0 | 67.4 | 175 | 2538 | 700 | 10152 | 640 | 4.18 | |||
