Home > Products > Other products > Taijia Ultrasonic Pulse Velocity Meter Ultrasonic Detector Ultrasonic Scanning Apparatus

Taijia Ultrasonic Pulse Velocity Meter Ultrasonic Detector Ultrasonic Scanning Apparatus

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Purpose Of CJ-10 Ultrasonic Pluse Detector

1.Testing of building foundation piles by cross-hole sonic logging
2.Inspection of concrete defects by ultrasonic method such as uncompacted , cellular, hole area. 3.Detecting defects of one hole by one trigger two receive.
4.Testing dynam performance of geotechnical investigation rock concrete etc.

Specification

item	CJ-10 Ultrasonic Pulse Detector
Place of Origin	China
Brand Name	Tmeasurement
Model Number	CJ-10
Temperature	-10℃ + 40℃
Weight	260mm x 185mm x 60mm
Sample Periods	0.05μs~6.4 8μs grades electable
Amplifier band width	5KHz~500 kHz
Amplifier gain	82dB
Receive sensitivity	<= 30μv
Trigger Voltage(V)	65,125,250,500,1000 selectable
Receive Channel	Two
Interface	USB
Storage	1G Internal 2G U-Disk

Features

CJ-10 Ultrasonic Pluse Detector

1.High efficient testing. Lifting speed is more than 60m/s.( 20 cm distance )
2.Display the test data graphically. User can watch analyze result directly
3.Fast and precise Automatic judge the sound parameters. Real-time wave display to assure test efficiency;
4.Humanized software design. Software design apply to User and construction plant. its help information ensure user handle easily
5.Linking the rebound apparatus directly. Detecting strength of concrete by ultrasonic-rebound combine method with linking rebound
apparatus directlyand get strength of concrete in time. The functions apply for national patent.
6.Being sensitive to receiving signal. Can receive signal more than 10m in concrete without defects
7.Can supply smooth power for radial energy transducer needless external power.
8.Standard USB storage with big capacity.
9.Interior lithium battery supply power for apparatus work more than 6 hours.
10.Portable, small, light apparatus (1.75Kg).
11.Extending function for testing thickness of concrete by impacting echo method. 12.Professional and powerful analysis software
on windows system. It can export the data to Excel or word for advanced analysis

Packing & Delivery

Carton for CJ-10 Ultrasonic Pulse Detector
