Module spare parts RV33-1

Focus on DCS, PLC, robot control system and large servo system.

Main products: various modules / cards, controllers, touch screens, servo drivers.

Advantages: supply of imported original products, professional production parts,

Fast delivery, accurate delivery time,

The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

. Insert the NI PXI-4351 into the selected 5 V slot. Use the injector/ejector handle to fully insert the device. 7. Use the screw on the front panel of the NI PXI-4351 to fasten the device to the front panel mounting rails of the PXI or CompactPCI chassis. 8. Visually verify the installation. 9. Plug in and power on the PXI or CompactPCI chassis. The NI PXI-4351 is now installed. Refer to the Configuring and Testing the NI 435X section next. ? NI PCI-4351 Figure 4. NI PCI-4351 with PC You can install the NI PCI-4351 in any available PCI expansion slot in the computer. However, to achieve the best noise performance, leave as much room as possible between the NI PCI-4351 and other boards and hardware. The following are general instructions, so consult the computer user manual or technical reference manual for specific instructions and warnings. 1. Write down the NI PCI-4351 serial number for future reference. 2. Plug in, but do not power on, the computer before installing the NI PCI-4351 device. The power cord grounds the computer and protects it from electrical damage while you are installing the module. 1 PC 2 NI PCI-4351 3 PCI Expansion Slot 1 2 3 Where to Start with the NI 435X 10 Caution To protect both yourself and the computer from electrical hazards, do not power on the computer until you finish installing the NI PCI-4351. 3. Remove the top cover or access port to the PCI bus. 4. Select any available PCI expansion slot. 5. Locate the metal bracket that covers the cut-out in the back panel of the chassis for the slot you selected. Remove and save the bracket-retaining screw and the bracket cover. 6. Touch the metal part of the power supply case inside the computer to discharge any static electricity that might be on your clothes or body. Caution The NI PCI-4351 is ESD/contamination sensitive. Handle the device using the metal bracket or edges. 7. Line up the NI PCI-4351 with the 68-pin connector near the cut-out on the back panel. Using slow, evenly distributed pressure, press the NI PCI-4351 straight down until it seats in the expansion slot. 8. Reinstall the bracket-retaining screw to secure the NI PCI-4351 to the back panel rail. 9. Visually verify the installation. 10. Replace the computer cover and power on the computer. The NI PCI-4351 is now installed. Refer to the Configuring and Testing the NI 435X section next.
