Ton bag weighing and packing machine

1. Basic overview of ton charter flights

Ton bag packing machine is used for large bag packing material weighing packaging equipment, it is a collection of electronic weighing, automatic bag removal, dust removal in one of the multi-purpose packing machine. Ton bag packing machine has high automation, high packing precision and adjustable packing speed. Working process by manual bagging, manual binding, the rest of the work: bag, bag blowing, feeding, measuring, with perfect detection and control function, reliable work, high measurement accuracy, simple operation, convenient maintenance. It is mainly used for packing large bags of materials in mineral, chemical, building materials, grain and feed industries.

2. Technical parameters

2.1. Weighing range: 1-2 tons/bag

2.2. Bagging capacity: 0-40 tons/hour

2.3. Accuracy: dynamic weighing ±0.5%

2.4. Power supply: 380V, 50HZ, 11KW

2.5. Air source pressure: 0.5mpa

2.6. Air consumption: 0.6m3/min

2.7. Dust removal air volume: 800-2500 m3/min

2.8. Relative humidity: ≤80%

2.9. Ambient humidity: -100°C-400°C

3. Technical characteristics

3.1 tons bag packing machine is tailored to the characteristics of powder materials and different requirements of the manufacturer. Advanced equipment technology, durable, less wearing parts.

3.2 Feeding, packaging stepless speed regulation, stable equipment performance, high packaging precision, fast speed.

3.3 Programmable electric control system, highly reliable control process.

3.4. Advanced dust and dust removal design, reducing dust pollution in the working environment.

3.5. The weighing system is an electronic scale, which adopts digital adjustment and parameter setting. It has functions such as cumulative weight display,
