Home > Products > Pillow Block Ball Bearing > FNL Flanged Housings FNL 520 FNL520A FNL520B pillow block Bearing FNL520
FNL Flanged Housings FNL 520 FNL520A FNL520B pillow block Bearing FNL520
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
3 Hole Flanged Bearing Unit FNL 511A FNL511B plummer block bearing FNL511
-
bearing factory SD split plummer block SD3138 TS Plummer Pillow Block Bearing SD 3136 SD 3138
-
SNL plummer block bearing housing SNL3236 Large split pillow block split bearings SNL3236
-
838607A peer Special Agricultural Bearings 838607 Farming Planter Bearing 204RY2 Round Bore 838607A
-
GE65-214 Radial insert ball bearings GE65-214-XL- KRR-B GE65-214KRRB inner 65mm
-
GE KRRB series insert ball bearings GE17KRRB GE17-XL-KRR-B inner 17mm
Product Description
Product Description
FNL Flanged Housings FNL 520 FNL520A FNL520B pillow block Bearing FNL520
These flanged bearing housings are designed to use self aligning ball bearings series 12 K and 22 K or spherical roller bearings series 222 K. Fixing of the bearings on the shaft is by means of an adapter sleeve.
LSBC supplies these housings for through shaft (Arrangement B) and as an end bearing housing with end cover (Arrangement A).
Flanged bearing housings series 7225.. are sealed with felt strip and designed for grease lubrication.
A R1/8" grease hole is incorporated in the housing for eventual later greasing. For shaft diameters 20 - 60 the housing is
supplied in a triangular form with 3 mounting bolts, for the shaft range 65 - 100 in square form with 4 mounting holes.
The bearing seat in the housing is designed with a bore tolerance H7 and for a floating bearing. Locating bearing arrangements are obtained by fitting the matching fixing rings between the housing shoulder and bearing outer race. 7225(00) Flanged bearing Housings are manufactured from grey cast.
LSBC supplies these housings for through shaft (Arrangement B) and as an end bearing housing with end cover (Arrangement A).
Flanged bearing housings series 7225.. are sealed with felt strip and designed for grease lubrication.
A R1/8" grease hole is incorporated in the housing for eventual later greasing. For shaft diameters 20 - 60 the housing is
supplied in a triangular form with 3 mounting bolts, for the shaft range 65 - 100 in square form with 4 mounting holes.
The bearing seat in the housing is designed with a bore tolerance H7 and for a floating bearing. Locating bearing arrangements are obtained by fitting the matching fixing rings between the housing shoulder and bearing outer race. 7225(00) Flanged bearing Housings are manufactured from grey cast.
bearing name | FNL Flanged Housings FNL 520 FNL520A FNL520B pillow block Bearing FNL520 |
Material : | bearing : chrome steel housing : cast iron |
bearing | FNL 520 |
adapter sleeve | H320 |
locating ring | FRB 10/180 |
email | sales1@landlionbearing.com |
Tel/ whatsapp | +86-18710180456 |
FNL Flanged Housings FNL 520 FNL520A FNL520B pillow block Bearing FNL520
Detailed Images
pillow block ball bearing type :
2 bolt Flange bearings units
3 bolt Flange bearings units
4-Bolt Flange Bearing Units
Take -up bearings
insert bearings
Related Products
Size Information
722500 plummer block housings Flanged housing
Product packaging
Packing ：
1. Industrial packing
2. Single box +carton +pallets /case
3. According to customers demand
Delivery time :
1. Generally after payment: within 3 days .
2. If need produce , about 30 days
Payment
A less USD1000 , 100% T/T in advance .
1. More USD1000 , 30% T/T in advance , 70%T/T before shipment
Shipping : by sea/by air/by express like EMS FEDEX TNT DHL...
Application
Factory
Company introduction
LANDLION BEARING CO.,LTD is an export-oriented enterprise, specializing in manufacturing and marketing several types of bearings for more than 10 years. We can produce the bearings accordingly to the customers' samples or drawings.LANDLION has a large top brand bearing NSK NTN UBC ASAHI IKO NACHI KOYO in stock.
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory and trader .
Q: How long is your delivery time?
A: Generally it is 1-3 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us .
