Home > Products > Thrust Roller Bearing > 80x170x54mm Spherical Roller Thrust Bearing 29416 29416E 29416M
80x170x54mm Spherical Roller Thrust Bearing 29416 29416E 29416M
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
29418 Spherical Roller Thrust Bearing 90x190x60MM bearing 29418E 29418M
-
NTN Thrust Roller Bearing 29413 Spherical Roller Thrust Bearing 29413 29413E 29413M
-
S.K.F. 29426 E Spherical thrust roller bearing 29426E 130X270X85
-
TIM KEN 29424 E Spherical thrust roller bearing 29424E
-
420*500*65 mm high quality LSBC 51184 thrust ball bearing 51184M
-
BA180-4 Travel Motor Large Bearing TZ200A1021-00 BA180-4BWSA for PC120-3 PC150-3 excavator
Product Description
Product Description
29416 Spherical Roller Bearing 29416E 29416M 29416-E1
80mm x 170mm x 54mm
80mm x 170mm x 54mm
29416 Spherical Roller Bearing, the 29416 inner diameter is 80mm, the 29416 outer diameter is 170mm and the 29416 width is 54mm.
* Item: 29416 Spherical Roller Bearing
* Type: Spherical Roller Bearing
* Dimensions: 80mm x 170mm x 54mm/Metric
* ID (inner diameter)/Bore: 80mm
* OD (outer diameter): 170mm
* Width/Height/thickness: 54mm
* Size: 80x170x54 mm
* Quantity: One Bearing
* Dynamic load rating Cr: 580,000 N
* Static load rating Cor: 1,630,000 N
* Limiting Speed: * Grease Lubrication: 1,500 RPM
* Oil Lubrication: 2,100 RPM
* Item: 29416 Spherical Roller Bearing
* Type: Spherical Roller Bearing
* Dimensions: 80mm x 170mm x 54mm/Metric
* ID (inner diameter)/Bore: 80mm
* OD (outer diameter): 170mm
* Width/Height/thickness: 54mm
* Size: 80x170x54 mm
* Quantity: One Bearing
* Dynamic load rating Cr: 580,000 N
* Static load rating Cor: 1,630,000 N
* Limiting Speed: * Grease Lubrication: 1,500 RPM
* Oil Lubrication: 2,100 RPM
Thrust Roller Bearings are available with cylindrical or spherical rollers. These bearings sustain only axial loads, but have high axial rigidity and are suitable for heavy loads. They contain convex rollers, have a self-aligning capability and are free of any influence of shaft deflection or mounting error. Standard cages are machined brass, where the E-type offers a pressed cage for high load capacity.
Bearings | Spherical Roller Bearing 29416E 29416M 29416-E1 |
d | 80mm |
D | 170mm |
B | 54mm |
weight | 5.9 KG |
Package | BOX,CARTON,WOODEN,PALLETS |
Payment | TT,WESTER UNION,PAYPAL |
Time | 3-5DAYS |
contact | 86-18710180456 |
email | sales1 at |
Detailed Images
29416-E1 - F A G Spherical Roller Thrust Bearing - 80x170x54mm
29416-E1 29416E 29416M
Axial spherical roller bearing
Axial spherical roller bearing
Recommend Products
Model No. | d (mm) | D (mm) | T(mm) | Weight (kg) |
29412 | 60 | 130 | 42 | 2.55 |
29413 | 65 | 140 | 45 | 3.2 |
29414 | 70 | 150 | 48 | 3.9 |
29415 | 75 | 160 | 51 | 4.65 |
29416 | 80 | 170 | 54 | 5.55 |
29317 | 85 | 150 | 39 | 2.7 |
29417 | 85 | 180 | 58 | 6.55 |
29318 | 90 | 155 | 39 | 2.83 |
29418 | 90 | 190 | 60 | 7.55 |
29320 | 100 | 170 | 42 | 3.6 |
29420 | 100 | 210 | 67 | 10.3 |
29322 | 110 | 190 | 48 | 5.25 |
29422 | 110 | 230 | 73 | 13.3 |
29324 | 120 | 210 | 54 | 7.3 |
29424 | 120 | 250 | 85 | 16.6 |
29326 | 130 | 225 | 58 | 8.95 |
29426 | 130 | 270 | 85 | 21.1 |
29328 | 140 | 240 | 60 | 10.4 |
29428 | 140 | 280 | 85 | 22.2 |
29330 | 150 | 250 | 60 | 10.8 |
29332 | 160 | 270 | 67 | 14.3 |
Product packaging
Packing ：
1. Industrial packing
2. Single box +carton +pallets /case
3. According to customers demand
Delivery time :
1. Generally after payment: within 3 days .
2. If need produce , about 30 days
Payment
A less USD1000 , 100% T/T in advance .
1. More USD1000 , 30% T/T in advance , 70%T/T before shipment
Shipping : by sea/by air/by express like EMS FEDEX TNT DHL...
Application
Factory
Company introduction
LANDLION BEARING CO.,LTD is an export-oriented enterprise, specializing in manufacturing and marketing several types of bearings for more than 10 years. We can produce the bearings accordingly to the customers' samples or drawings.LANDLION has a large top brand bearing NSK NTN UBC ASAHI IKO NACHI KOYO in stock.
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory and trader .
Q: How long is your delivery time?
A: Generally it is 1-3 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us .
