Home > Products > Cylindrical Roller Bearing > Medium and Large Machines Bearing 05269067 Excavator Walking Bearing 3-252 Size 260*320*80mm 319262B
Medium and Large Machines Bearing 05269067 Excavator Walking Bearing 3-252 Size 260*320*80mm 319262B
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
CPM2168 Cylindrical Roller Bearings CPM2168.RNN 40*57.81*34
-
65x93.09x46mm Gearbox Reducer Bearing CPM2652 Cylindrical Roller Bearing CPM2652
-
65X93.1X58mm Gearbox Reducer Bearing CPM2527 Cylindrical Roller Bearing CPM2527
-
SL06 Full Complement Cylindrical Roller Bearing SL06032 SL06032E 160x240x110mm
-
TJ-602-662 KOYO Cylindrical Roller Bearing TJ602662 for Gear Reducer
-
CPM2400 CPM 2400 Cylindrical Roller Bearing 24X40.25X26 mm
Product Description
Product Description
05269067 Excavator walking bearing 3-252 size 260*320*80mm
319262B Bearing
F6666.1 bearing
319262 Bearing F-6666.1
Cylindrical roller bearing are of high load capacity and can operate at high speeds because they use rollers as their rollingelements. They can therefore be used in applications involving heavy radial and impact loading.
The rollers are cylindrical in shape and crowned at the end in order to reduce the stress concentrations. They are also suitablefor applications that require high speed because the rollers are guided by ribs which are either on the outer or inner ring.
The rollers are cylindrical in shape and crowned at the end in order to reduce the stress concentrations. They are also suitablefor applications that require high speed because the rollers are guided by ribs which are either on the outer or inner ring.
Indexing roller units E3-252
Bearing number : E3-252
Size (mm) : 260x320x80
Bore Diameter (mm) : 260
Outer Diameter (mm) : 320
Width (mm) : 80
Bearing dimensions and specification in catalogue:
d - 260 mm
D - 320 mm
B - 80 mm
d1 - - 291.78 mm
D1 - - 294.37 mm
r1,2 - min. - 2 mm
r3,4 - min. - 2 mm
Basic dynamic load rating - C - 142 kN
Basic static load rating - C0 - 240 kN
Fatigue load limit - Pu - 22.8 kN
Maximum dynamic radial loads - Fr - max. 96.5 kN
Maximum static radial loads - F0r - max. 137 kN
Mass roller unit - 15 kg
Tags : INA , 260x320x80
Bearing number : E3-252
Size (mm) : 260x320x80
Bore Diameter (mm) : 260
Outer Diameter (mm) : 320
Width (mm) : 80
Bearing dimensions and specification in catalogue:
d - 260 mm
D - 320 mm
B - 80 mm
d1 - - 291.78 mm
D1 - - 294.37 mm
r1,2 - min. - 2 mm
r3,4 - min. - 2 mm
Basic dynamic load rating - C - 142 kN
Basic static load rating - C0 - 240 kN
Fatigue load limit - Pu - 22.8 kN
Maximum dynamic radial loads - Fr - max. 96.5 kN
Maximum static radial loads - F0r - max. 137 kN
Mass roller unit - 15 kg
Tags : INA , 260x320x80
E3-252 Engineered Bearing roller bearing
sales1@landlionbearing.com +86-18710180456
Construction machinery bearing E3-252 HS718 HS723 NNF5852 319262 319262B Roller bearing excavator bearing
Cylindrical roller bearing E3-252 road pavement street roller bearing 3-252
Cylindrical Roller Bearing SIZE AS FOLLOWING:
Principal dimensions | Basic load ratings | Fatigue load limit | Maximum radial loads | Designation | ||||||||
dynamic | static | dynamic | static | |||||||||
d[mm] | D[mm] | B[mm] | C[kN] | C0[kN] | Pu[kN] | Frmax.[kN] | F0rmax.[kN] | |||||
110 | 210 | 110 | 286 | 360 | 40.5 | 265 | 380 | 319008 A/HB2 | ||||
120 | 210 | 114 | 336 | 550 | 64 | 320 | 455 | BCZ-0087 | ||||
120 | 210 | 114 | 369 | 520 | 60 | 290 | 415 | 319181/HB2 | ||||
140 | 250 | 114 | 528 | 765 | 86.5 | 335 | 480 | 316977 C | ||||
140 | 280 | 114 | 682 | 980 | 112 | 560 | 800 | BC2B 320055 A | ||||
160 | 250 | 140 | 539 | 830 | 90 | 310 | 450 | BNTB 326247/HB1 | ||||
260 | 320 | 80 | 142 | 240 | 22.8 | 96.5 | 137 | 319262 B | ||||
Recommend Products
Product packaging
Packing ：
1. Industrial packing
2. Single box +carton +pallets /case
3. According to customers demand
Delivery time :
1. Generally after payment: within 3 days .
2. If need produce , about 30 days
Payment
A less USD1000 , 100% T/T in advance .
1. More USD1000 , 30% T/T in advance , 70%T/T before shipment
Certifications
Shipping : by sea/by air/by express like EMS FEDEX TNT DHL...
Application
Factory
Company introduction
LANDLION BEARING CO.,LTD is an export-oriented enterprise, specializing in manufacturing and marketing several types of bearings for more than 10 years. We can produce the bearings accordingly to the customers' samples or drawings.LANDLION has a large top brand bearing NSK NTN UBC ASAHI IKO NACHI KOYO in stock.
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory and trader .
Q: How long is your delivery time?
A: Generally it is 1-3 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us .
