Home > Products > Angular Contact Ball Bearing > Spindle Bearing B7000-C-2RSD-T-P4S-UL Precision Angular Ball Bearing B7000-C-2RSD-T-P4S-UL 10x26x8 mm
Spindle Bearing B7000-C-2RSD-T-P4S-UL Precision Angular Ball Bearing B7000-C-2RSD-T-P4S-UL 10x26x8 mm
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
7000C Hybrid Ceramic Ball Bearings 7000C HQ1/P4 High Precision Spindle Bearing 7000C/HQ1P4 10x26x8mm
-
High Speed HCB 7008 -C-T-P4S-UL Hybrid Ceramic Bearing for Spindle Bearings 7008CHQ1P4
-
7016 CNC Spindle Bearings 7016 CHQ1P4 Ceramic Ball Bearing 7016 P4
-
High Quality 7011C HQ1P4 DT DB Precision Hybrid Ceramic Bearing 7011CHQ1P4 Spindle Bearings 7011
-
High-speed Nsk Spindle Bearing 50BNR10 Angular Contact Ball Bearing 50BNR10XTYNV1VDBBC01 Ball Screw
-
7210 CTRSULP3 NSK Bearing 50x90x20 Spindle Bearing 7210 P3 P4 P2 Grade
Product Description
Product Description
Spindle Bearing / Precision Angular Ball Bearing B7000-C-2RSD-T-P4S-UL 10x26x8 mm
bearing Features
* it is suitable for high radial and axial loads in one direction
* it has also an axial load carrying capacity on both sides in the X- or O-arrangement in pairs
* medium series for a broad range of applications
* accuracy grade: P4S (main dimensions at least according to ISO-tolerance class 4)
* all running tolerances are classified according to ISO-tolerance class 2
* it is designed for a high running accuracy and high speeds with maximum rigidity and operational safety
* not separable
* The mounting orientation is identifiable by the colour of the seals. The side with the higher shoulder is marked by a red seal, the opposite seal is black. This colour coding of the seals allows to see and check the mounting orientation, even when the bearing is already assembled.
* material: 100Cr6 (rolling bearing steel), phenol resin (cage)
* seal: 2RSD (2-side non contact rubber seal)
* temperature resistance up to circa 80°C in the long run, temporarily up to circa 120°C
* it is suitable for high radial and axial loads in one direction
* it has also an axial load carrying capacity on both sides in the X- or O-arrangement in pairs
* medium series for a broad range of applications
* accuracy grade: P4S (main dimensions at least according to ISO-tolerance class 4)
* all running tolerances are classified according to ISO-tolerance class 2
* it is designed for a high running accuracy and high speeds with maximum rigidity and operational safety
* not separable
* The mounting orientation is identifiable by the colour of the seals. The side with the higher shoulder is marked by a red seal, the opposite seal is black. This colour coding of the seals allows to see and check the mounting orientation, even when the bearing is already assembled.
* material: 100Cr6 (rolling bearing steel), phenol resin (cage)
* seal: 2RSD (2-side non contact rubber seal)
* temperature resistance up to circa 80°C in the long run, temporarily up to circa 120°C
name | Spindle Bearing / Precision Angular Ball Bearing B7000-C-2RSD-T-P4S-UL |
ID | 10MM |
OD | 26MM |
B | 8MM |
Product weight | 0.02kg |
Cage Material: | Phenolic Resin |
material | chrome steel |
contact us | sales1 at |
delivey time | after payment 3days |
Related Products
bearing | d | D | B | c | Da | da | contact angle | weight KG |
B7000-C-2RSD-T-P4S-UL | 10 | 26 | 8 | 6.4 | 22 | 14 | 15° | 0.02 |
B7001-C-2RSD-T-P4S-UL | 12 | 28 | 8 | 6.7 | 24.5 | 16.5 | 15° | 0.02 |
B7002-C-2RSD-T-P4S-UL | 15 | 32 | 9 | 7.6 | 28 | 19 | 15° | 0.03 |
B7003-C-2RSD-T-P4S-UL | 17 | 35 | 10 | 8.5 | 32 | 21 | 15° | 0.04 |
B7004-C-2RSD-T-P4S-UL | 20 | 42 | 12 | 10.2 | 37 | 25 | 15° | 0.07 |
B7005-C-2RSD-T-P4S-UL | 25 | 47 | 12 | 10.8 | 42 | 30 | 15° | 0.08 |
B7006-C-2RSD-T-P4S-UL | 30 | 55 | 13 | 12.3 | 49 | 36 | 15° | 0.11 |
B7007-C-2RSD-T-P4S-UL | 35 | 62 | 14 | 13.5 | 56 | 41 | 15° | 0.15 |
B7008-C-2RSD-T-P4S-UL | 40 | 68 | 15 | 14.7 | 62 | 46 | 15° | 0.19 |
B7009-C-2RSD-T-P4S-UL | 45 | 75 | 16 | 16 | 69 | 51 | 15° | 0.24 |
B7010-C-2RSD-T-P4S-UL | 50 | 80 | 16 | 16.7 | 74 | 56 | 15° | 0.25 |
B7011-C-2RSD-T-P4S-UL | 55 | 90 | 18 | 18.7 | 83 | 62 | 15° | 0.38 |
B7012-C-2RSD-T-P4S-UL | 60 | 95 | 18 | 19.4 | 88 | 67 | 15° | 0.4 |
Product packaging
Packing ：
1. Industrial packing
2. Single box +carton +pallets /case
3. According to customers demand
Delivery time :
1. Generally after payment: within 3 days .
2. If need produce , about 30 days
Payment
A less USD1000 , 100% T/T in advance .
1. More USD1000 , 30% T/T in advance , 70%T/T before shipment
Shipping : by sea/by air/by express like EMS FEDEX TNT DHL...
Application
Factory
Company introduction
LANDLION BEARING CO.,LTD is an export-oriented enterprise, specializing in manufacturing and marketing several types of bearings for more than 10 years. We can produce the bearings accordingly to the customers' samples or drawings.LANDLION has a large top brand bearing NSK NTN UBC ASAHI IKO NACHI KOYO in stock.
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory and trader .
Q: How long is your delivery time?
A: Generally it is 1-3 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
