Product Description
Product Description
H7008C 2RZ HQ1 P4 DB sealed hybrid ceramic bearing 7008C2RZHQ1P4DB DF DT spindle bearings 7008
Structure-Ceramic Ball/Angular Contact ball
Model number- H7008C2RZHQ1P4DB
seal: sealed
Size :Inner ring(mm)-40 Outer ring(mm)-68 Width(mm)-15 Weight(Kg)-0.17kg
Materials-Chrome steel/GCR15
Precision grade-P4/P2
Lubrication type-Grease lubrication
Contact Angle-C=15°;AC=25°
Material(Ball)-SN24:Ceramic ball(Si3N4)
Number of Row-Single rows
Material(Cage)-TN /PN
Combination-
SU:Universal combination (single row)
DU:Universal combination (double rows)
DB: Back-to-back combination
DF: Face-to-face combination
DT: Parallel combination
DBD.DFD.DTD: Three rows
DBB.DFF.DBT.DFT.DTT: Four rows
DB: Back-to-back combination
DF: Face-to-face combination
DT: Parallel combination
DBD.DFD.DTD: Three rows
DBB.DFF.DBT.DFT.DTT: Four rows
Categories:Angular Contact Ball Bearings Ceramic Ball Bearings
Related Search:7008AC / CHQ1P4,7008C Ceramic Ball Bearings,7009C Spindle bearing,7008C High Speed Bearing
Product Features
Angular Contact Ball bearing with Ceramic balls (Si3N4), used in high precision Spindle and Motors
Series Introduction
High Speed Ceramic Ball Type:ISO 10 Series - highest load, second lowest speed
bearings-70 Series Angular Contact Bearings Series
Model No.
7000HQ1,7001HQ1,7002HQ1,7003HQ1,7004HQ1,7005HQ1,7006HQ1,7007HQ1,7008HQ1,7009HQ1,
7010HQ1,7011HQ1,7012HQ1,7013HQ1,7014HQ1,7015HQ1,7016HQ1,7017HQ1,7018HQ1
Applications High Speed Ceramic Ball Angular contact bearing applications :
electric motors,Spindle,automotive applications, home appliances, industrialequipment
Product Features
Angular Contact Ball bearing with Ceramic balls (Si3N4), used in high precision Spindle and Motors
Series Introduction
High Speed Ceramic Ball Type:ISO 10 Series - highest load, second lowest speed
bearings-70 Series Angular Contact Bearings Series
Model No.
7000HQ1,7001HQ1,7002HQ1,7003HQ1,7004HQ1,7005HQ1,7006HQ1,7007HQ1,7008HQ1,7009HQ1,
7010HQ1,7011HQ1,7012HQ1,7013HQ1,7014HQ1,7015HQ1,7016HQ1,7017HQ1,7018HQ1
Applications High Speed Ceramic Ball Angular contact bearing applications :
electric motors,Spindle,automotive applications, home appliances, industrialequipment
• metal cutting and woodworking machinery spindles
• other machine spindles (e.g. balancing machines)
• high speed rolling mills
• printing machinery
• precision ball screws
• live centres
• high speed turbochargers
• vacuum pumps
• racing cars
• boat gyrostabilizers
• machine components for the semiconductor industry
• other machine spindles (e.g. balancing machines)
• high speed rolling mills
• printing machinery
• precision ball screws
• live centres
• high speed turbochargers
• vacuum pumps
• racing cars
• boat gyrostabilizers
• machine components for the semiconductor industry
name | H7008C 2RZ HQ1 P4 DB sealed hybrid ceramic bearing S7008 CEGA / HCP4A for spindle bearings |
ball material | Si3N4 |
ID | 40mm |
OD | 68mm |
B | 15mm |
Product weight | 0.17kg |
Cage Material: | TN |
material | chrome steel |
seal | sealed or Open |
Tel | +86-18710180456 sara |
H7008C 2RZ HQ1 P4 DB sealed hybrid ceramic bearing S7008 CEGA / HCP4A for spindle bearings 7008 P4Hybrid ceramic bearing back tp back
the bearing picture :
Related Products
High Speed Ceramic Ball Angular contact bearing applications
bearing | d | D | B | c | Da | da | contact angle | weight KG |
B7000-C-2RSD-T-P4S-UL | 10 | 26 | 8 | 6.4 | 22 | 14 | 15° | 0.02 |
B7001-C-2RSD-T-P4S-UL | 12 | 28 | 8 | 6.7 | 24.5 | 16.5 | 15° | 0.02 |
B7002-C-2RSD-T-P4S-UL | 15 | 32 | 9 | 7.6 | 28 | 19 | 15° | 0.03 |
B7003-C-2RSD-T-P4S-UL | 17 | 35 | 10 | 8.5 | 32 | 21 | 15° | 0.04 |
B7004-C-2RSD-T-P4S-UL | 20 | 42 | 12 | 10.2 | 37 | 25 | 15° | 0.07 |
B7005-C-2RSD-T-P4S-UL | 25 | 47 | 12 | 10.8 | 42 | 30 | 15° | 0.08 |
B7006-C-2RSD-T-P4S-UL | 30 | 55 | 13 | 12.3 | 49 | 36 | 15° | 0.11 |
B7007-C-2RSD-T-P4S-UL | 35 | 62 | 14 | 13.5 | 56 | 41 | 15° | 0.15 |
B7008-C-2RSD-T-P4S-UL | 40 | 68 | 15 | 14.7 | 62 | 46 | 15° | 0.19 |
B7009-C-2RSD-T-P4S-UL | 45 | 75 | 16 | 16 | 69 | 51 | 15° | 0.24 |
B7010-C-2RSD-T-P4S-UL | 50 | 80 | 16 | 16.7 | 74 | 56 | 15° | 0.25 |
B7011-C-2RSD-T-P4S-UL | 55 | 90 | 18 | 18.7 | 83 | 62 | 15° | 0.38 |
B7012-C-2RSD-T-P4S-UL | 60 | 95 | 18 | 19.4 | 88 | 67 | 15° | 0.4 |
Product packaging
Packing ：
1. Industrial packing
2. Single box +carton +pallets /case
3. According to customers demand
Delivery time :
1. Generally after payment: within 3 days .
2. If need produce , about 30 days
Payment
A less USD1000 , 100% T/T in advance .
1. More USD1000 , 30% T/T in advance , 70%T/T before shipment
Shipping : by sea/by air/by express like EMS FEDEX TNT DHL...
Application
Factory
Company introduction
LANDLION BEARING CO.,LTD is an export-oriented enterprise, specializing in manufacturing and marketing several types of bearings for more than 10 years. We can produce the bearings accordingly to the customers' samples or drawings.LANDLION has a large top brand bearing NSK NTN UBC ASAHI IKO NACHI KOYO in stock.
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory and trader .
Q: How long is your delivery time?
A: Generally it is 1-3 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us .
