Product Description
Most popular in 2016 wood charcoal kiln/palm kernel shell charcoal making machine/coconut shell biochar furnace
A: Structure:
This carbonization furnace is the cylinder shape. And this model stove consists of outer stove, inner stove, and fume extraction tube, smoking purification tank and hoisting equipment.
B: Raw material could be:
Wood log, tree, tree branch, wood briquette, coconut shell, palm nutshell, Walnut Shell, Macadamia nutshell, bamboo, and other nut shell or hard raw material
C: Working principle:
The surface of wood (bamboo, wood briquette, nut shell, etc) will ignite spontaneously in the hypoxic condition. And this spontaneous combustion will produce heat. This heat and the external heat source will heat the stove at the same time, when the temperature reach 280 degree, the chemical structure of the wood will be changed by the high-temperature, and after long time heating, changing and decomposing, then we will get the black charcoal, combustible gas, and wood tar. This model furnace will use the fume extraction tube to recycle all the combustible gas and smoking from the entire heat source.
D: Main data:
| model | capacity | inner volume | temperature | machine include |
| QHL-1 | 1.5-2t/24h | 2.75*3 | 400-600degree | 1outer stove, 3inner stoves with 3 caps, 1 3ton lifting device, 1smoking tank |
| QHL-2 | 3-4t/24h | 2.75*6 | 400-600 degree | 2 outer stove, 6 inner stoves with 6 caps, one 5-ton hoisting equipment with e-motor, 1smoking tank |
| QHL-3 | 4.5-6t/24h | 2.75*9 | 400-600 degree | 3 outer stove, 9 inner stoves with 9caps, one 5-ton hoisting equipment with e-motor, 1smoking tank |
| QHL-4 | 6-8t/24h | 2.75*12 | 400-600 degree | 4 outer stove, 12 inner stoves with 12caps, one 5-ton hoisting equipment with e-motor, 4smoking tank |
E: other parts of the furnace:
1. Inner stove and covers, Raw material to make the furnace:
2. Valves for the furnace:
3. Outer stove inside and Purification tank:
