Product Description

Touch screen	7-inch touch screen, easy to use, fast response
Compatible with reagent kits	You can use reagents from various manufacturers.
Multi-mode operation	Scan code, list, shortcut, view methods
Free programming	Powerful program editing function to meet the needs of different reagents
Fast extraction	Short operation time, 10-30 minutes (related to the reagent), 32 samples can be extracted at the same time.
Extraction efficiency	The purification scheme can be optimized according to different reagents, and achieve higher extraction efficiency and purity.
Stable and reliable	The whole process is automatic, avoiding differences and errors caused by manual operation, stable results and good repeatability.
Pollution prevention and control	Built-in UV disinfection function, regular disinfection, eliminating cross contamination.
Safe and reliable	When the safety door is opened, the program will pause automatically, and continue to operate if the safety door is closed, avoiding injuries.

Size（Length X width X Height）	35cm X 35cm X 41.5cm
Weight	About 17Kg
Power supply	AC220V，50Hz/60Hz，150W
Maximum process volume	1200μL
Maximum sample throughput	32
Recovery of magnetic beads	>95%
Plate types	96 deep-well plate
Magnetic rod	32
Heating temperature range	Optional heating module ( RT- 99 ℃ )
Oscillatory mixing	Multistage, adjustable
Adaptable consumables	96 deep-well plates, magnetic rod sleeves

Ordering information for supporting consumables:

Ordering No	Product Name	Specification
7-0002-13	96 2.2mL deep-well plate	50 pics/box
7-005-02	8-well magnetic rod	500 pics/box

<<< CLICK HERE TO VIEW MORE PRODUCTS NOW

The principle of AMTK® ME-32 nucleic acid extractor is the magnetic beads adsorption method by the magnetic rod. The system is composed of 32 magnetic rod, heating module and control system. It's compatible with different nucleic acid extraction reagents with magnetic beads. It has the characteristics of high cost performance, high timeliness and high openness.

Features and advantages: √Screen operation: inch touch color screen, graphical operation interface, easy to use, fast response, no need for an external computer. √ Reagent opening: Compatible with a variety of kits to meet the needs of nucleic acid extraction from different samples. √Free programming: powerful program editing function, free and flexible editing and extraction program. √Multi-mode operation: scan code, list, shortcut, view. √ Pollution prevention and control: built-in UV disinfection function, which can be disinfected regularly to prevent cross-contamination. √Quick extraction: The operation time is short, and the extraction is completed in 9-30 minutes (related to the reagent). √Stable and reliable: The whole process is completed automatically, avoiding differences and errors caused by manual operation, and the results are stable and repeatable. √High safety: automatically suspend the program operation after the safety door is opened, and continue to run the program after the safety door is closed to avoid injury Application areas: Nucleic acids can be extracted and purified from blood, plasma, saliva, oral swab, virus, animal tissue, plant tissue, bacteria and microbial samples. It can be applied in clinical disease diagnosis, CDC, forensic identification, molecular breeding, food safety detection and other fields. Equipment composition: √Magnetic rod √Magnetic rod sleeve √96 deep-well plate √Main control interface Software interface √UV √Heating module

working principle:

The magnetic beads adsorbed with nucleic acid were moved to different reagent well, and then the liquid was quickly and repeatedly stirred using the stirring sleeve on the outer layer of the magnetic rod to make the liquid and magnetic beads evenly mixed. And nucleic acid with high purity is finally obtained after cell lysis, nucleic acid adsorption, cleaning and elution.

Manufacturing Technique

Company Profile

AMTK was founded in 2004 by a group of elites in design of sophisticated devices. Our headquarter bases in Beijing ZhongGuanCun - the heart of Chinese tech center. AMTK established its 2500M2 GMP rated manufacturing facility in Suzhou in 2016. AMTK is a tech pioneer. We are proud of making nation's first HPLC autosampler and the first high throughput liquid handler in China. AMTK is also an application-driven company. We have developed many workstations for third-party medical laboratories,hospitals,blood stations,CDC,research institutes.

Certificate

Exhibition

Packing & Delivery

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

FAQ

1.Why choose AMTK Biotechnology Co., Ltd.? We are a professional company and the leading of fully automatic sample pretreat-ment in China. Meanwhile, we provide OEM and ODM service to our clients.

2.How to transport the product? A: We transport the product as your requirement. Depending on the quantity and the machine you orderor whether you are urgent or not,we will suggest you suitable transportation way, by air or by sea.

3. What kind of packing way for product? A: Depends on which kind product you order.Most of products are packed with cartons. Some productsare packed with wooden boxes.All of the packing way is based on the safety of the product.

4.What kind of warranty will be offer? A: The warranty of our products varies from 12 months.
