Medfuture Three Area Mini PCR Work Station For PCR Lab Rapid Nucleic Acid Detection

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

MedFuture Mini PCR Workstation

Product Description

Features1:

* Small dimension, save space,economical and convenient.
* Large LCD display, all information displayed.
* Automatic air speed adjustable with filter block.
* With memory function in case of power-failure.
* Side & back wall is made up of single piece stainless steel.
* Interlock function: UV lamp and front window; UV lamp and blower, fluorescent lamp; Blower and front window.
* Audio and visual alarm:Filter replacement, window over height, abnormal air flow velocity etc.

Features2:

* Front 7° slanted to offer operator comfort while working for long time, reduce glare and maximize reach into the work area.
* Time reserve function: This can setthe UV lamp and fan working time.
* It is divided into three areas, each area does not interfere with each other; the three areas are closely designed to reduce the
sample transfer time between each area and improve the efficiency of rapid nucleic acid detection.

Model	PCR- mini
External Size（LWH）mm			21007101900	16007001900
Reagent Preparation Area	Operating Area Size（LWH）mm	640570510	440570500
		Pressure	Positive
		Airflow Velocity（m/s）	0.45
		Airflow Volume（m3/h）	420	310
		Exhaust Type	-
Specimen Preparation Area	Operating Area Size（LWH）mm	660570510	560570500
		Pressure	Negative
		Airflow Velocity（m/s）	Downflow: 0.33±0.025 Inflow: 0.53±0.025
		Airflow Volume（m3/h）	250	210
		Exhaust Type	TypeA2, 30% exhaust, 70% recirculation
Amplification Analysis Area	Operating Area Size（LWH）mm	640570510	440570500
		Pressure	Negative
		Airflow Velocity（m/s）	0.4
		Airflow Volume（m3/h）	180	160
		Exhaust Type	100% exhaust
HEPA Filter	Four, 99.999% efficiency at 0.3μm. Filter life indicator.
Clean Level	Class 100
Front Window	Manual, Toughened glass, Anti UV
Max Opening	380mm
Noise	≤67 dB（A）
Vibration	≤5μm
UV Lamp	15W*3, UV timer, UV life indicator, emission of 253.7 nanometers for most efficient decontamination
LED Lamp	8W*3
Illumination（lx）	≥650( Each area)
Sockets	The load of two sockets (Each area): 500W, total 6 sockets
Display	LCD
Control System	Microprocessor
Visual and Audio Alarm	Filter replacement, window over height, abnormal air flow velocity
Work Surface Height	750 mm
Material	Work Zone: 304 stainless steel Main Body: Cold-rolled steel with anti-bacteria powder coating
Power Supply	AC220V±10%, 50/60Hz; 110V±10%, 60Hz
Consumption	500W
Standard Accessory	LED lamp3, UV lamp4, Windproof plate2, Waterproof sockets6
Package Size (WDH)	22409701450mm			17509801440mm
Gross Weight	450kg			330kg

If you are interested in our products, please let me know without delay.
