BIOBASE China Auto Hematology Analyzer BK-3100 Latest Product Blood Cell Counter Hematology for Lab

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

BIOBASE

Hematology analyzer

BK-3100

Feature:

1.9.7-inch color touch LCD screen, easy to operate, display all parameters and histograms on the same screen.

2. Fewer samples are required for testing: whole bloodS10μl, pre-diluteds 20μl.

3.60 samples/hour.

4.21 parameters + 3 histograms.

5. It can be turned on continuously for 24 hours.

6. Automatically clean the sampler, counting pool and pipeline after starting up.

7. Built-in thermal printer, external printer can be connected.

8. Electrical impedance method, cyanide-free detection of HGB.

9. Fully itelligent blockage removal and alarm function.

10. Both automatic calibration and manual calibration are available.

11. Counting Mode: Venous, capilary, prediluted.

12. Support LIS system.

Specification

Model	BK-3100
Throughput	60 samples/hour
Principle	Impedance for WBC differentiation and WBC/RBC/PLT count; Colorimetric method for HGB
Channels	2
Parameters	21 parameters(including WBC, Mid#, Lym#, Gran#, Mid%, Lym%, Gran%, RBC, HGB, HCT, MCV, MCH, MCHC,RDW-SD, RDW-CV, PLT, MPV,PDW，PCT, P-LCR, P-LCC)
Histograms	3 histograms (including WBC, RBC, PLT histograms)
Sample Volume	Whole blood: 10μl, Prediluted: 20μl
Calibration	Manual, auto calibration
Counting Modes	Venous, capilary, prediluted
Printing Model	Auto print, manual print
LIS	Support Bi-directional LIS
Language	Chinese, English, Spanish, French, Russian, Ukrainian
Reagent	Diluent 20L, Hemolytic agent 500ml, Probe cleanser: 50ml
Data Input	9.7-inch touch screen, mouse, keyboard (optional)
Output	Internal printer, support external printer
Printer paper	57*30mm
Interface	4 USB ports, network port，RS232 serial port.
Storage	100,000 results with histogram
Unclog	High voltage burn, reverse high-pressure flush
Work Temperature	15-30°C
Power Supply	100~240 AC, 50/60Hz, 150VA
Relative Humidity	30﹪～85﹪
Atmospheric Pressure	70.0kPa-110.0kPa
Carry-over rate	Parameter	WBC	RBC	HGB	PLT
Carry-over rate		CV	≤ 1.5%	≤ 1%	≤ 1%	≤ 3%
Background	Parameter	WBC	RBC	HGB	HCT	PLT
Background		Background	≤ 0.3×109/L	≤ 0.03×1012/L	≤ 1 g/L	≤ 0.5%	≤ 10×109/L
Linearity	Parameter	Measurement range			CV
		WBC	(0.5~10.00×109)/L (10.10~99.9×109)/L			(±0.5×109)/L ±5%
		RBC	(0.05~1.00×1012)/L (1.01~9.99×1012)/L			(±0.05×1012)/L ±5%
		HGB	(2~70g)/L (71~300.0g)/L			(±2.0g)/L ±2%
		PLT	(10~100×109)/L (101~999×109)/L			(±10.0×109)/L ±8%
Precision	Parameter	Whole blood (CV)	Pre-diluted （CV）	Measurement range
		WBC	≤ 2.0%	≤ 4.0%	(4.0-15.0×109)/L
		RBC	≤ 1.6%	≤ 3.0%	(3.5-6.0×1012)/L
		HGB	≤ 1.6%	≤ 3.0%	(110.0-180.0g)/L
		MCV	≤1.0%	≤2.0%	(70.0-120.0)fL
		PLT	≤ 4.0%	≤8.0%	(150.0-500.0×109)/L
External Size(WDH)	295467418mm
Packed Size(WDH)	404564616mm
Net weight	19 KG
Gross weight	31KG
