550kg Price New Mini Hand Held Manual Vibrating Hydraulic Double Drum Road Roller Compactor
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Double Drum Mini Road Roller/Walk Behind Double Drum Hydraulic Vibratory Mini Road Roller
-
Small 700kg Hand Road Roller Compactor
-
Single Drum Road Roller Walk Behind Mini Road Roller Mini Road Roller
-
Concrete Laser Screed Machine Road Floor Leveling Machine
-
Concrete Road Pavers Machine Price
-
High Power Engineering Lighting Tower Mobile Vehicle-mounted Diesel Light Tower Mobile
Product Description
Product Description
550kg price new mini hand held manual vibrating hydraulic double drum road roller compactor
1. It is mainly used for the compaction and leveling of ditch foundations, roads and stadiums. It can also be used for the compaction of asphalt surface.
2. The operation radius is small, it can work in smaller area, and is suitable for trench backfill.
3. Equipped with international famous brand HONDA gasoline engine or excellent diesel engine, its performance is superior and easy to start.
4. Adopt international famous brand hydraulic drive import unit, stepless speed change, front and rear walking, hydraulic steering.
5. Start mechanical and electrical start, hydraulic vibration, operation easier and more convenient.
6. Install luxurious seats, adjust conveniently and work comfortably.
The internationally famous NSK bearing ensures the working performance of the machine.
Surface sprayed, beautiful face, rust and corrosion resistance
550kg price new mini hand held manual vibrating hydraulic double drum road roller compactor
Technical Parameters
Technical Data for Hengwang Double drum hand roller compactor | ||||||||
Model | HW600C | HW650B | HW650C | |||||
Engine | Engine model | GX270 | CF178 | R180 | ||||
Engine type | Gasoline 4 stroke | Diesel 4 stroke | Diesel 4 stroke | |||||
Engine power | 9HP 3600rpm | 6HP 3600rpm | 8HP 2400rpm | |||||
Oil tank | 3.5L | 3.5L | 4.5L | |||||
Fuel consumption rat | 395g/kw.h | 280g/kw.h | 313g/kw.h | |||||
Size | Width of steel drum | 600mm | 600mm | 600mm | ||||
Diametere of steel drum | 426mm | 426mm | 426mm | |||||
Total length | 2450mm | 2450mm | 2450mm | |||||
Total width | 780mm | 780mm | 780mm | |||||
Total height | 1800mm | 1800mm | 1800mm | |||||
Package size | 1350*850*1200mm | 1350*850*1250mm | 1350*850*1250mm | |||||
Weight | Machine weight | 530kg | 550kg | 590kg | ||||
Walking | Walking speed | 0-4km/h | 0-4km/h | 0-4km/h | ||||
Gradeability | 30% | 30% | 30% | |||||
Compaction | Nominal amplitude | 0.6mm | 0.6mm | 0.6mm | ||||
vibrational frequency | 75HZ | 75HZ | 75HZ | |||||
exciting force | 20KN*2 | 20KN*2 | 20KN*2 | |||||
Water tank | 20L | 20L | 20L | |||||
Working | Drive | Vibration | ||||||
Hydraulic pump and motor - two wheel drive | ||||||||
Automatic drive - double wheel vibration | ||||||||
550kg price new mini hand held manual vibrating hydraulic double drum road roller compactor
Detailed Images
Packing & Delivery
550kg price new mini hand held manual vibrating hydraulic double drum road roller compactor
