3ton Spider Crane with Telescopic Boom Diesel and Electric Small Remote Control Cranes
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
HW-SPC3 Small Lift Crane Telescopic Mini Crawler Spider Crane With Cheap Price For Sale
-
Hengwang HW-3T Factory Direct Sale Spider Crawler Crane Mini Spider Crawler Telescopic Crane Lift
-
Hengwang HW-3T Price Mini Spider Crane New Mini Spider Crawler Crane For Sale
-
Hengwang HW-3T New Hot Sale Hydraulic Mini Spider Crane Price
-
1 Year Warranty Hydraulic Telescopic 3 tons Mini Spider Crawler Crane For Sale
-
Remote Control 3 ton Mini Spider Crane With Torque Limiter
Product Description
Product Description
Hengwang Mini Spider Crane Crawler Crane With Hydraulic Telescopic Outrigger Small Cranes
Product features:
*Proportional remote control and proportional valve (optional)
*Moment limiter (optional)
*380 V power supply
*Outrigger by remote control (optional)
*Five section boom and double connecting cylinder
*1.2 m height of body
*U boom
*Take the elevator
*One key for the level of body (optional)
*Interlock system
*Travel available by forklift truck
*Remote control walking (optional)
*Sensor of outrigger on the ground
*Proportional remote control and proportional valve (optional)
*Moment limiter (optional)
*380 V power supply
*Outrigger by remote control (optional)
*Five section boom and double connecting cylinder
*1.2 m height of body
*U boom
*Take the elevator
*One key for the level of body (optional)
*Interlock system
*Travel available by forklift truck
*Remote control walking (optional)
*Sensor of outrigger on the ground
Specification
Product Name | Spider Crane | HW3.0 | |
Specification | 2.95T*1.3M | ||
ing radius | 8.3m*0.14T | ||
Max.Ground lifting height | 9.2m | ||
Max.underground lifting height | - | ||
Winch device | Hook speed | 6.5m/min(4 sections) | |
Rope type | φ7.7mm*45m | ||
Telscopic system | Boom type | Full automatic 5 section | |
Boom length | 2.56-8.92m | ||
Telescopic length/time | |||
Up and downs | Boom angle/time | 0-75°/14sec | |
Slew system | Slew angle/time | 0-360°（continuous）40sec | |
Outrigger | Max.Extended Dimensions | 3900mm*3750mm | |
Traction system | Walking way | Hydraulic motor driven | |
Walking speed | 0-2.9km/h | ||
Ground length*width*2 | 1010*200mm*2 | ||
Grade ability | 20 | ||
Ground pressure | 51Kpa | ||
Safety devices | Onekey leveling, torque limiter, height limiter, crane outrigger sensor, alarm device, emergency button | ||
System voltage | DC12V | ||
Diesel engine(optional) | Model | 3TNV70 | |
Displacement | 0.854L | ||
Max. output | 10.3KW | ||
Starting method | Electric starting | ||
Fuel tank capacity | 11L | ||
Opersting temperature | -5℃-40℃ | ||
Battery capacity | 12V 45Ah | ||
Petrol engine | model | CH440 | |
Displacement | 429ml | ||
max.output | 14hp | ||
Starting method | recoil start/electric starting | ||
Fuel tank capacity | 7.4L | ||
Opersting temperature | -5℃-40℃ | ||
Battery capacity | 12V 45Ah | ||
Electic motor | power supply voltage | (standard) AC380V | |
Remote control | Type | BO*1.1(Optional) | |
Operating range | 100m | ||
water-proof standards | IP67 | ||
Dimension | Length*width*height | 2900*800*1580mm | |
Weight | Vehicle weight | 2050KG | |
Product Detail
Detailed images of mini spider crane.
Detailed images of mini spider crane.
Small crane 3 ton
Spider crane structure
