Asphalt Road Cold Milling Machine 1M For Road Marking Removal Machine

FOB Price

Negotiable

1 (Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Asphalt Road Cold Milling Machine 1M For Road Marking Removal Machine

Contact way:

Contact Way

Annie Li

Mobile / Whatsapp / Wechat: +86138 1769 0558

Evangel(shanghai)Industrial Co,Ltd

Evangel International Machinery Ltd

Add: Suite 2806, Super Ocean Finance Center,

No. 2067 West Yan'an Road, Shanghai, China

Web:

Product Description

ENGINE POWER

With 160kW/2200rpm, this engine conforms to China-III emission regulation.

OVERALL WEIGHT

14500kg

MILLING WIDTH

1000mm

Drive system

SDEC electronically controlled engine conforms to the China-III non-road machinery emission regulation, featuring high intelligence and efficiency, high parts universality, and low maintenance cost.
The energy-saving technologies, including automatic idling of engine, are utilized to realize better fuel economy, low emission load, and high working efficiency for the whole machine.
The milling drum is driven by mechanical belt and the drive belt is hydraulically tensioned, featuring high drive efficiency, effectively mitigated operating impact, and stable and reliable power transmission.

Easy maintenances

The structural parts inherit the excellent quality of Shantui’s mature products.
The large opening design for engine hood and side doors provides a spacious room for maintenances.
The core electric and hydraulic parts adopt imported products, featuring stable and reliable quality and extremely high reliability.
The external fuel/oil filter and grease nozzles are installed in hanging manner to ease the maintenances and replacement.

Parameter name	SM100MT-3 (Standard version)
Performance parameters
Operating weight (Kg)	15200
Transport weight(Kg)	14500
Maximum milling width (mm)	1000
Maximum milling depth (mm)	300
Engine
Engine model	SC9D
Rated power/rated speed (kW/rpm)	160/2200
Overall dimensions
Overall dimensions of machine (mm)	1221023852545
Driving performance
Traveling speed (km/h)	0-8
Working speed (m/min)	0-30
Conveyor System
Width of conveyor belt (mm)	500
Swing angle of conveyer (Rightward/leftward) (°)	25/20
Tank capacity
Fuel tank (L)	540
Working device
Number of milling cutters (Piece)	94

Detailed Images:
