Home > Products > Road Construction Machinery > Tyre Vibratory Roller 26ton Hydraulic Pneumatic Tire Roller Price
Tyre Vibratory Roller 26ton Hydraulic Pneumatic Tire Roller Price
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
Vibratory Roller 20 Ton Tire Road Roller Compactor CLG6520E
-
Chinese brand 215H Original Manufacturer use Gr260 China Motor Graders CLG4215
-
Chinese brand 215H Road Building Machinery Gr165 Motor Grader And Hydraulic Pump CLG4215
-
Road Construction Machines New Type 16 Ton Vehicle Type Hydraulic Roller
-
Chinese brand 215H use Grader Gr100 And Motor Grader Cylinder Spare Parts Price List CLG4215
-
13 Ton Low Oil Consumption Double Drum Steam Road Roller
Product Description
Tyre Vibratory Roller 26ton Hydraulic Pneumatic Tire Roller Price
Contact way:
Contact Way
Annie Li
Mobile / Whatsapp / Wechat: +86138 1769 0558
Evangel(shanghai)Industrial Co,Ltd
Evangel International Machinery Ltd
Add: Suite 2806, Super Ocean Finance Center,
No. 2067 West Yan'an Road, Shanghai, China
Web:
Product Description
Top quality compaction is achieved by the kneading and rolling effect of the wheels as vertical pressure combined with horizontal forces produce an excellent, uniform surface finish.
On uneven surfaces, our patented Tire Suspension System, equipped with a tiltable front shaft, enables the 4 front wheels to swing up and down by +/- 8° achieving maximum ground contact for each wheel. This delivers optimum compact and improves safety by helping prevent the roller from tilting over.
Safety is further enhanced with a three-stage breaking system utilizing hydraulics, oil cut-off and wheel side oil breaking.
This three stage system protects the operator, site workers and members of the public from accidents.
Parameters
| Model | 6516E | 6520E | 6526E | 6530E |
| Max. Operating Mass | 16000 kg | 20000 kg | 26000 kg | 30000 kg |
| Min. Operating Mass | 11000 kg | 11000 kg | 15000 kg | 15000 kg |
| Single Tire Load | 1778 kg | 2222 kg | 2364 kg | 2727 kg |
| Overlapping of Front & Rear Tire | 45 mm | 45 mm | 45 mm | 45 mm |
| Model | 4BTAA3.9-C130 | QSB4.5-C130 | Shangchai SC7H180.2G3 | Shangchai SC7H180.2G3 |
| Emission Regulation | Stage II | Stage III | Stage III | Stage III |
| Rated Power | 97 kW (132 hp) @ 2200 rpm | 97 kW (132 hp) @ 2200 rpm | 132 (179 hp) @ 2200 rpm | 132 (179 hp) @ 2200 rpm |
| Working Speed | 0-7 km/h | 0-7 km/h | 0~7 km/h | 0~7 km/h |
| Traveling Speed | 0-16 km/h | 0-16 km/h | 0~15 km/h | 0~15 km/h |
| Compacting Width | 2250 mm | 2250 mm | 2750 mm | 2750 mm |
| Theoretical Gradeability | 20% | 20% | 20% | 20% |
| Min. Ground Clearance | 290 mm | 290 mm | 360 mm | 360 mm |
| Wheelbase | 3600 mm | 3600 mm | 3840 mm | 3840 mm |
| Min. Outside Turning Radius | 8000 mm | 8000 mm | 9000 mm | 9000 mm |
| Tire Type | 11.00-20-16PR | 11.00-20-16PR | 11.00-20-16PR | 11.00-20-16PR |
| Tire Numbers | Front 4 Rear 5 | Front 4 Rear 5 | Front 5 Rear 6 | Front 5 Rear 6 |
| Overall Length | 4800 mm | 4800 mm | 4970 mm | 4970 mm |
| Overall Width | 2310 mm | 2310 mm | 2800 mm | 2800 mm |
| Overall Height | 3270 mm | 3270 mm | 3340 mm | 3340 mm |
