New 130 Tons Truck Crane SAC1300T With All Terrain Crane Chassis and 73m Main Boom Price

Can be as good as 220 ton crane!

Vehicle gross weight: 55000kgs

Engine: Weichai WP12 460E50

Rated power: 338kw

Gradeability: 46%

Main boom/arm: 73m

Boom+jib: 100.2m

Basic arm maximum lifting torque: 5175KN.m

Main boom and jib maximum lifting height: 100.5m

Minimum turning radius: 8.5m

Gearbox: Z-F

Transfer case: Kess-ler

Axle: Kess-ler

Suspension: oil-gas suspension

Main oil pump: Rex-roth or Dan-foss

Motor: Kawa-saki

The main arm is fully extended by 73 m, and the maximum elevation of the main arm + jib is 100.2m;
Mechanical single-engine transmission, high transmission efficiency, no risk of escalation on board;
Full-surface chassis, all-wheel steering, minimum turning radius of 8.5m, flexible maneuvering;
The parts are made of international famous brands, Germany Z-F gearbox, Ke-sller transfer case, Ke-sller axle, Rex-roth main pump, efficient and reliable.

Size parameters
The whole length of the machine: 15530mm
The full width of the machine: 2800mm
The whole machine height: 4000mm

Dynamic parameter
Maximum engine power: 338/1900Kw/rpm
Maximum output torque of the engine: 2150/1000-1400N.m/rpm

Driving parameters
Maximum travel speed: 80Km/h
Minimum turning radius (at the tire): 8.5m
Approach angle ≥19.5o
Departure angle ≥16o
Maximum grade: 46%
100 km fuel consumption: ≤ 70L

Performance parameter
Maximum rated total lifting capacity: 130t
Turntable tail turning radius: 4.86m
Maximum lifting torque (basic arm): 5116kN.m
Maximum lifting torque (full extension main arm): 2058kN.m
Outrigger span (horizontal × longitudinal): 8.4 × 7.9m

Working speed parameter
Main winch single rope maximum speed (no load): 130m/min
Sub-winding single rope maximum speed (no load): 130m/min
Main arm full arm time: 600s
Full starting time of the boom: 55s
Rotation speed: 1.5r/min
