Telescopic Handler Forklift 45T Container Handler
- T/T Credit Card
You May Like
-
China Best Quality Port Stacker 45T Hydraulic Container Reach Stacker Forklift SRSC45H
-
45Ton Manual Forklift Hydraulic Manual Stacker
-
45 Ton Hydraulic Container Reach Stacker Forklift
-
45Ton Reachstacker Forklift Truck Port Machinery
-
45Ton Telescopic Reach Forklift With Top Pick Container Handler
-
45 Tons Energy-Saving Forklift Container Reach Stacker With Euro Iii
Product Description
45 ton reach stacker heli container handler port forklift RSH4527 for sale
Product Features
(1) Design Standards: Designed by well-known European port machiner company(harbor machinery company), the truck is synchronized with the technical level of same period European product. The truck with higher security not only meets national standards but also EU standards (EN1459;ISO15018).
(2) Drivelines: Vollvo Power meeting national emission standard level 3 (EU3) is assembled on the truck. This model possesses strong drive power and good weather-resistance.
(3) Transmission: The model is assembled with originally imported Z--F transmission with smooth and high efficient gear shifting.
(4) Drive axle: The truck is assembled with originally imported Kessler axle with wet disc brakes specially designed for heavy trucks, meeting continuous operation in poor working conditions and maintenance-free requirements.
(5) Hydraulic system:
American Parker’s constant-power-variable-displacement hydraulic system with high efficiency and fuel economy is assembled on the truck. The innovative design of self-cleaning hydraulic cooling system extends the interval between oil changes and reduces the total cost of the machine ownership. Advanced techniques such as load sensing, dual pump converging, and small flow under high pressure are applied to save energy and reduce the cost.
(6) Electronic controlling system: We choose the CAN-bus system from 3B6 (Italia), which can display various information in both Chinese and English on a 6.5inch color screen, including the weight of cargo, the immediate length and angle of the boom, LMI, anti-rollover, buffer limit, vertical lift, the quantity of containers, etc. The information is displayed automatically without inputting any orders.
(7) High strength structure components: Heavy-duty box-type chassis makes the foundation of long-lasting high performance.
Technical Parameters
| Model | RSH4528-VO2 | RSH4532-VO2 | RSH4536-VO2 | ||
|---|---|---|---|---|---|
| RSH4528-CU | RSH4532-CU | RSH4536-CU | |||
| Lifting capacity | LC1/LC2/LC3 | Kg | 45000/28000/14000 | 45000/32000/16000 | 45000/36000/19000 |
| Load center | LC1/LC2/LC3 | mm | 1800/3850/6400 | 1800/3850/6400 | 1800/3850/6400 |
| Lifting height at LC1 | mm | 15050 | |||
| Spreader | Sideshift | mm | +800~-800 | ||
| Rotation | ° | -95~+185 | |||
| Turning radius | mm | 8590 | |||
| Boom angle | deg | 60 | |||
| Length | mm | 11670 | |||
| Width | mm | 4060 | |||
| Engine | VOLLVO TAD1151 CUMMMINS QSM11 | ||||
| Transmission (gears forward/reverse) | DAANA TE27(4/4) | ||||
| Driving axle | Kessler | ||||
| Driving brake system, type | Wet disc brakes | ||||
