Home > Products > Lifting Machinery > Cheap Price ZOOMLION 55 Ton Hydraulic Truck Crane ZTC550
Cheap Price ZOOMLION 55 Ton Hydraulic Truck Crane ZTC550
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
ZOOMLION 50ton Mobile Truck Crane ZTC500A
-
Popular ZOOMLION 25ton Telescopic Boom Mobile Truck Crane ZTC251V451
-
High Quality New Moibile Truck Crane 70ton QY70KH
-
70 Ton Truck Crane 70 Ton Hydraulic Truck Crane QY70KH
-
50ton Telescopic Crane Lattice Crane 50ton Hydro Crane. 50ton QY50KD
-
50ton Crane Truck Crane 50ton QY50KD
Product Description
Cheap price ZOOMLION 55 ton hydraulic truck crane ZTC550
1. Full-width cab,
2. LHD,
3. 4-axle,
4. Gear pump hydraulic system, hydraulic control operation,
5. WEICHAI engine WP9H336 247kW,
6. 5-section U-shaped boom(11.6-45.0m),
7. two-section jib (9.5m, 16m),
8. two winches,
9. chassis and up cab cool and heat A/C,
10. Two-stage outrigger, double-sided operation outrigger,
11. Pitch mechanism with control room,
12. Counterweight 6ton, and 2ton auxiliary counterweight,
13. Three acousto-optic alarm lamp, slewing monitor system and parking camera,
14. standard 50t main hook, 4t auxiliary hook.
2. LHD,
3. 4-axle,
4. Gear pump hydraulic system, hydraulic control operation,
5. WEICHAI engine WP9H336 247kW,
6. 5-section U-shaped boom(11.6-45.0m),
7. two-section jib (9.5m, 16m),
8. two winches,
9. chassis and up cab cool and heat A/C,
10. Two-stage outrigger, double-sided operation outrigger,
11. Pitch mechanism with control room,
12. Counterweight 6ton, and 2ton auxiliary counterweight,
13. Three acousto-optic alarm lamp, slewing monitor system and parking camera,
14. standard 50t main hook, 4t auxiliary hook.
|
ZTC500A
|
|||
|
Item
|
Unit
|
Value
|
|
|
Working performance
|
Max. rated lifting capacity
|
kg
|
55000
|
|
Max. load moment of basic boom
|
kN.m
|
1813
|
|
|
Max. load moment of main boom(fully extended)
|
kN.m
|
1082
|
|
|
Max. lifting height of basic boom
|
m
|
12.6
|
|
|
Max. lifting height of main boom
|
m
|
45.5
|
|
|
Max. lifting height of jib
|
m
|
61
|
|
|
Working speeds
|
Max. hoist rope speed(Main winch)
|
m/min
|
135
|
|
Max. hoist rope speed(Auxiliary winch)
|
m/min
|
125
|
|
|
Boom demrricking up time
|
s
|
50
|
|
|
Boom telescoping out time
|
s
|
110
|
|
|
Slewing speed
|
r/min
|
0-2.2
|
|
|
Driving parameters
|
Max. height above sea level
|
m
|
2000
|
|
Max. driving speed
|
km/h
|
80
|
|
|
Max. gradeability
|
%
|
44
|
|
|
Min. turning diameter
|
m
|
24
|
|
|
Min. ground clearance
|
mm
|
280
|
|
|
Oil consumption per hundred kilometers
|
L
|
41
|
|
|
Mass
|
Deadweight in driving condition
|
kg
|
41600
|
|
Complete vehicle kerb mass
|
kg
|
41405
|
|
|
Front axle load
|
kg
|
15600
|
|
|
Rear axle load
|
kg
|
26000
|
|
|
Engine
|
Engine model
|
WP9H336
|
|
|
Rated power
|
kW
|
247
|
|
|
Dimensions
|
Overall dimensions(L×W×H)
|
mm
|
14100x2650x3800
|
|
Outrigger spread(L)
|
m
|
7.4
|
|
|
Outrigger spread(W)
|
m
|
6.05(Full)/4.88( Intermediately)
|
|
|
Tail slewing radius
|
mm
|
3890
|
|
|
Main boom length
|
m
|
11.6-45
|
|
|
Boom angle
|
°
|
-2~80
|
|
|
jib length
|
m
|
9.5, 16
|
|
|
Offset
|
°
|
0 15 30
|
|
