ZOOMLION New 260t Crawler Crane ZCC2600

FOB Price

Negotiable

1 (Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

ZOOMLION new 260t crawler crane ZCC2600

Product Description

Item			Unit	Value
Maximum lifting capacity × radius			t × m	260 × 5
Deadweight of crane with basic boom			t	210
Length of main boom		S-boom length	m	20-83
		SL-boom length	m	86-95
F-jib length			m	12~30
Max.lifting capacity on fixed jib			t	34
F-jib angle			.	10,30
Max. length of heavy duty boom with fixed jib			m	77+30
W-jib Length			m	21-60
Max. lifting capacity on luffing jib			t	73.5
S-boom angle( for SW boom configuration)			.	65-85
Max. length of heavy duty boom with luffing jib			m	62+60
Single rope speed of winches	Hoisting winch 1		m/min	130
	Hosting winch 2		m/min	120
	Main boom derricking winch		m/min	80× 2
Slewing speed			rpm	0-1.2
Traveling speed			km/h	0-1.0
Max.gradeability			%	30
Ground pressure			MPa	0.115
Transport weight of max.single unit			t	32
Rear counterweight			t	83.7
Central counteweight			t	32
Engine	Manufacturer			US Cumins
	Rated power/rotational speed		Kw/rpm	227/2000
	Max. output torque/rotational speed		Nm/rpm	1505/1400
	Emission standard			U.S.EPA Tier 3 and EU Stage III A

EFFICIENT, QUICK AND SAFETY

The mechanism operating speed up 20%, and the speed of each mechanism don’t slow down

while operating 2 functions simultaneously;

Time of erecting the whole crane is less than 6 hours;

Omni-directional real-time LMI and monitoring system, to ensure safety operation.

CONVENIENT, COMFORTABLE AND INTELLIGENCE

The max. Single transport weight is 30.5t, transport width is 3m;

Omni-directional vehicle information platform, real time monitoring equipment operation,

The IOT intelligent interaction system make the mobile service come true.

Full view cabin, buttons and switches are all within reach,

all-around air conditioner form a comfortable operating space.
