2022 Evangel 160Hp Shantui Crawler Bulldozer SD16 With Good Engine
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
2022 Evangel New Shantui 160Hp Wetland Crawler Bulldozer in Stock
-
2022 Evangel Hydraulic Transmission System Shantui Bulldozer Widely In Uzbekistan
-
2022 Evangel Shantui Brand 160hp Sd16 Bulldozer
-
2022 Evangel China Shantui 160hp Crawler Bulldozer SD16 At Lower Price
-
2022 Evangel Famous Brand Shantui Bulldozer With Accessories
-
2022 Evangel Construction Machinery 160hp Shantui Bulldozer With Undercarriage Parts
Product Description
Hydraulic System Shantui SD16 Bulldozer
Contact way:
Contact Way
Annie Li
Mobile / Whatsapp / Wechat: +86138 1769 0558
Evangel(shanghai)Industrial Co,Ltd
Evangel International Machinery Ltd
Add: Suite 2806, Super Ocean Finance Center,
No. 2067 West Yan'an Road, Shanghai, China
Web:
Product Description
The all-purpose customer choice
Engine model: Shangchai SC11CB184G2B1/Weichai WD10G178E25
Net power: 120 kW/160HP/1850 rpm
Operating weight: 17 t
| PRODUCT | SD16 | ||
| PERFORMANCE PARAMETERS | Operatiing Weight (kg) | 17000 | |
| Rated horsepower (kw/hp) | (120/160) | ||
| Minimum turning radius (mm) | 4466 | ||
| Ground pressure (kpa) | 58 | ||
| ENGINE | Model | Weichai WP10G178E355/Shangchai SC11CB184G2B1 | |
| Emission | China II | ||
| Type | In-line,direct injction,4-cycles,water cooled,turbocharged | ||
| No.of cylinders×Bore×stroke (mm×mm) | 6-126×130/6-121×152 | ||
| Piston displacement (L) | 9.726/10.5 | ||
| Horsepower/rpm (kw/rpm) | 131/1850,135/1850 | ||
| Maximum torque (N.m/r/min) | 764/1300 | ||
| DIMENSIONS | Length(mm)X Width(mm)X Height(mm) | 5140×3388×3032 | |
| TRAVELING PERFORMANCE | Forward(km/h) | F1:0~3.29 | |
| F2:0~5.82 | |||
| F3:0~9.63 | |||
| Reverse(km/h) | R1:0~4.28 | ||
| R2:0~7.59 | |||
| R3:0~12.53 | |||
| Gradeability(deg) | 30° | ||
| Clearance(mm) | 400 | ||
| UNDERCARRIAGE | Suspension | Swing type of sprayed beam,suspended structure of equalizer bar | |
| Track gauge (mm) | 1880 | ||
| Shoe width (mm) | 510(560,610) | ||
| Track length on ground (mm) | 2430 | ||
| Number of shoes (each side) | 37 | ||
| Pitch (mm) | 203 | ||
| Carrier rollers (each side) | 2 | ||
| Track rollers (each side) | 6 | ||
| WORKING HYDRAULIC SYSTEM | Pressure(Mpa) | 14 | |
| Working pump | Gear pump | ||
| Valve | Multi-way valve | ||
| Bore of blade lift cylinder (mm) | Φ110 | ||
| Bore of blade tilt cylinder (mm) | Φ160 | ||
| Bore of ripper lift cylinder(mm) | Φ160 | ||
| TANK CAPACITY | Fuel tank capacity (L) | 315 | |
| Working hydraulic tank capacity (L) | 110 | ||
| WORKING EQUIPMENT | Blade width (mm) | 3388 | |
| Blade height (mm) | 1149 | ||
| Blade capacity (m³) | 4.5 | ||
| Max.Drop below ground of blade | 540 | ||
| Lift height of blade | 1095 | ||
| Maximum lifting height of ripper (mm) | 572 | ||
| Maximum digging depth of ripper (mm) | 592 | ||
Detailed Images:
