T&L Brand CNC Servo Motor Turret Punching Machine With Fanuc
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
T&L Brand CNC Turret Punching Machine for Sale China Turret Punching Machine
-
T&L Brand CNC Turret Punching Machine Metal Turret Punching Machine With Fanuc System
-
T&L Brand CNC Punching Machine Punch Press Servo Turret Punch Cnc
-
T&L Brand High Quality Cnc Turret Punch Tooling, Punch Press
-
T&L Brand CNC Punching Machine Metal Sheet, Punching Machine on Metal Plate
-
T&L Brand Top Quality CNC Servo Sheet Metal Punching Machine Price
Product Description
Company Information
|
Product Description
| Main Features: |
| 1. Dual-servo motor driven system, adopts large torque direct driven servo motor and driving unit with high overload capacity to realize low energy consumption, high transmission efficiency, reliable performance and convenient maintenance |
| 2. The turret with bushing is process in pairs |
| 3. Imported pneumatic, lubricating and electric components ensure the reliability of the whole machine |
| 4. Large lead guideway and ballscrew from Japan or Germany ensures high feeding precise |
| 5. It adopts fixed and moveable worktable, plastic worktable plate, full brush table with lifting balls for loading to reduce the workload and auxiliary working time during sheet loading |
| 6. O-type welded frame has been vibrated for twice, the stress has been deleted completely. The frame is processed by Germany SHW dual-side pentahedron processing center at one time, no need to make second time positioning CNC Servo motor turret punching machine with Fanuc |
| 7. Floating clamp with large clamping force ensures the stable feeding; integrated carriage ensures good rigidity and convenient movement of clamp turret punch |
| 8. X axis adopts gear rack structure driven by servo motor and reduction box, Y axis adopts dual-ballscrew driven by dual servo motors, this structure features with fast feeding speed, high precise and stable feeding |
| 9. Central lubrication system is adopted to send the lubrication grease to the relative lubricating point directly, reducing the friction of each working pairs and increasing the service life. CNC punching machine price, punch press machine |
Product Overviews
Our Services
| 1. Standard Service: |
|
Our factory provide the service for the customer forever, if the customer need operation help, can contact us by MSN, Skype, Email and Telephone at any time, we provide 24 hours on-line service. |
| 2. Installation: |
|
Our factory can send our engineer to the customer’s factory install, commission and training freely .The customer provide the double trip tickets, food and accommodation for our engineer. The customer also can send the engineer to our factory to learn the operation and maintains freely. |
| 3. Quality Guarantee: |
|
Our guarantee time is 24 months from B/L Date ,If any component is damaged during guarantee time,we can send the component to the customer By DHL,TNT freely. |
| 4. Order Processing: |
|
Packaging & Shipping
FAQ
|
Requirement for Customer: |
| 1. Hydraulic oil: imported VG46# anti-wear hydraulic oil; and the required oil mass depend on the machine specification |
| 2. Environment temperature: 0°C - +40°C |
| 3. Environment humidity: relative humidity 20-80%RH(non-condensing) |
| 4. Keep away from the strong vibration source and electromagnetic interference |
| 5. Prepare the foundation according to the foundation drawing |
| 6. Voltage fluctuation 10%--5% |
Contact Us
- T&L (Shanghai) International Trading Co., Ltd.
