Home > Products > PLC/Temperature Controller/Flame Control > LS PLC K7M-DR20U/DR30U/DR40U/DR60U K7M series 100%brand new
LS PLC K7M-DR20U/DR30U/DR40U/DR60U K7M series 100%brand new
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
LG/LS K7M-DRT20U Master K120S Series 100%brand new K7M-DRT20/30/40/60U
-
Fatek PLC FBS- series FBS-10MAR2-AC 100% brand new FBS-14MAR2-AC/FBS-20MAR2-AC/FBS-24MAR2-AC/FBS-32MAR2-AC/FBS-40MAR2-AC/
-
Fatek PLC FBS- series FBS-10MCR2-AC 100% brand new FBS-14MCR2-AC/FBS-20MCR2-AC/FBS-24MCR2-AC/FBS-32MCR2-AC/FBS-40MCR2-AC/FBS-14M
-
Fatek PLC FBS- series FBS-10MAT2-AC 100% brand new FBS-14MAT2-AC/FBS-20MAT2-AC/FBS-24MAT2-AC/FBS-32MAT2-AC/FBS-40MAT2-AC/FBS-60
-
Fatek PLC B1/B1Z series B1Z-10MR2-AC 100% brand new
-
Fatek PLC B1/B1Z series B1Z-10MR2-D24S 100% brand new B1Z-20MR2-D24S/B1Z-24MR2-D24S/B1Z-32MR2-D24S/B1Z-40MR2-D24S/B1Z-20MT2-D24S
Product Description
PLC is a high performance PLC for the LS production department of LG group of Korea.
The master-k series has two types: unit type and module type. The unit type has Master-K(following MK)10S1, MK10S, MK30S, MK60S, mk80, etc. There are 3 types of modules: MK200S, MK300S and MK1000S. The unit type is equipped with CPU, Digital I/O, Power and other parts in PLC body, which is not only simple, but also convenient for small space setting. The Power, CPU, Digital I/O and special modules with special functions have been unitized in the module type, so the customer can set up the system according to their own requirements. Characteristics hold various types of Master-K series according to need control I/O points, with 14~1,024 points of various optimization models. High speed running calculation (up to 0.2 s/step), real-time control/monitoring output point and input point. All kinds of special function modules hold control/measure temperature, humidity, flow rate, air volume simulation module and control servo motor's position control module and other special function modules. Strong network rs-232c/rs-485 basic communication equipment, Fieldbus, Modbus, DNet and other communication networks. The kgl-win Software for the entire module of the programmable master-k series is available for Windows 95/98/NT O/S configuration, which can be exchanged with GSIKGL and kgl-dos.
K7M-DR10UE dc 24V6 input/relay 4 point output.
The master-k series has two types: unit type and module type. The unit type has Master-K(following MK)10S1, MK10S, MK30S, MK60S, mk80, etc. There are 3 types of modules: MK200S, MK300S and MK1000S. The unit type is equipped with CPU, Digital I/O, Power and other parts in PLC body, which is not only simple, but also convenient for small space setting. The Power, CPU, Digital I/O and special modules with special functions have been unitized in the module type, so the customer can set up the system according to their own requirements. Characteristics hold various types of Master-K series according to need control I/O points, with 14~1,024 points of various optimization models. High speed running calculation (up to 0.2 s/step), real-time control/monitoring output point and input point. All kinds of special function modules hold control/measure temperature, humidity, flow rate, air volume simulation module and control servo motor's position control module and other special function modules. Strong network rs-232c/rs-485 basic communication equipment, Fieldbus, Modbus, DNet and other communication networks. The kgl-win Software for the entire module of the programmable master-k series is available for Windows 95/98/NT O/S configuration, which can be exchanged with GSIKGL and kgl-dos.
K7M-DR10UE dc 24V6 input/relay 4 point output.
Some other models.
K7M-DR20U dc 24V12 input/relay 8 point output.
K7M-DR30U dc 24V18 input/relay 12 point output.
K7M-DR40U dc 24V24 input/relay 16-point output.
K7M-DR60U dc 24V36 input/relay 24 point output.
K7M-DRT20U dc 24V12 input/relay 4 point output + transistor 4 point output.
K7M-DRT30U dc 24V18 input/relay 8 point output + transistor 4 point output.
K7M-DRT40U dc 24V24 input/relay 12 point output + transistor 4 point output.
K7M-DRT60U dc 24V36 input/relay 20 point output + transistor 4 point output.
K7M-DT20U dc 24V12 input/relay 8 point output.
K7M-DT30U dc 24V18 input/relay 12 point output.
K7M-DT40U dc 24V24 input/relay 16-point output.
K7M-DT60U dc 24V36 input/relay 24 point output.
K7M-DR10UE dc 24V6 input/relay 4 point output.
K7M-DR14UE dc 248 point input/relay 6 point output.
K7M-DR20UE dc 24V12 input/relay 8 point output.
K7M-DR30UE dc 24V18 input/relay 12 point output.
G7e-dc08a dc 24V8 input extension.
G7e-ry08a relay 8 point output extension.
G7e-dr08a dc 24V4 point input/relay 4 point output extension.
G7e-dr10a dc 24V6 input/relay 4 point output extension.
The g7e-tr10a transistor is extended at 10 o 'clock.
G7e-dr20a dc 24V12 input/relay 8 point output extension.
G7f-adha analog input/output unit (2 channel input /1 output, 12BIT)
G7f-adhb analog input/output unit (2 channel input /2 output, 12BIT)
G7f-ad2a analog input unit (4-channel input, 12BIT)
G7f-da21 analog input unit (4-channel current signal, 12BIT)
G7f-da2v analog input unit (4-channel current signal, 12BIT)
G7f-at2a analog potentiometer 4 g7f-rd2a thermal resistance temperature detection 4 channel.
G7l-cuebrs-232c communication unit g7l-cuecrs-422 (485)
Communication unit g7l-dbeadevicenet from station module g7l-pbeaprofibus-dp.
From the station module g7l-fueaf -NET communication module.
G7l-ruear-net communication module.
G7e-rtca real-time clock card.
G7M-M256B program backup card.
K7M-DR30U dc 24V18 input/relay 12 point output.
K7M-DR40U dc 24V24 input/relay 16-point output.
K7M-DR60U dc 24V36 input/relay 24 point output.
K7M-DRT20U dc 24V12 input/relay 4 point output + transistor 4 point output.
K7M-DRT30U dc 24V18 input/relay 8 point output + transistor 4 point output.
K7M-DRT40U dc 24V24 input/relay 12 point output + transistor 4 point output.
K7M-DRT60U dc 24V36 input/relay 20 point output + transistor 4 point output.
K7M-DT20U dc 24V12 input/relay 8 point output.
K7M-DT30U dc 24V18 input/relay 12 point output.
K7M-DT40U dc 24V24 input/relay 16-point output.
K7M-DT60U dc 24V36 input/relay 24 point output.
K7M-DR10UE dc 24V6 input/relay 4 point output.
K7M-DR14UE dc 248 point input/relay 6 point output.
K7M-DR20UE dc 24V12 input/relay 8 point output.
K7M-DR30UE dc 24V18 input/relay 12 point output.
G7e-dc08a dc 24V8 input extension.
G7e-ry08a relay 8 point output extension.
G7e-dr08a dc 24V4 point input/relay 4 point output extension.
G7e-dr10a dc 24V6 input/relay 4 point output extension.
The g7e-tr10a transistor is extended at 10 o 'clock.
G7e-dr20a dc 24V12 input/relay 8 point output extension.
G7f-adha analog input/output unit (2 channel input /1 output, 12BIT)
G7f-adhb analog input/output unit (2 channel input /2 output, 12BIT)
G7f-ad2a analog input unit (4-channel input, 12BIT)
G7f-da21 analog input unit (4-channel current signal, 12BIT)
G7f-da2v analog input unit (4-channel current signal, 12BIT)
G7f-at2a analog potentiometer 4 g7f-rd2a thermal resistance temperature detection 4 channel.
G7l-cuebrs-232c communication unit g7l-cuecrs-422 (485)
Communication unit g7l-dbeadevicenet from station module g7l-pbeaprofibus-dp.
From the station module g7l-fueaf -NET communication module.
G7l-ruear-net communication module.
G7e-rtca real-time clock card.
G7M-M256B program backup card.
