Small Benchtop Plastic PET Preform and Cap Injection Molding Machine
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Plastic Injection Moulding Machine for Bottle Preforms / Caps
-
PET Preform Machine Price,bottle Pet Preform Machine,mineral Water Bottle Pet Preform Machine
-
130-750ton Pet Preform Making Machine/injection Moldiang Machine/pet Preform Machine
-
Moulds Mould Maker Plastic Injection Mold
-
Plastic Injection Pvc Fitting Mould Making Factory
-
High Quality Cheap Customized Plastic Cap Molds From Mold Manufacturer
Product Description
Product Description
INJECTION UNIT | ||||||||
ITEM | UNIT | VALUE | ||||||
SCREW DIAMETER | mm | 30 | 35 | 40 | ||||
SCREW L/D RATIO | L/D | 24.5 | 21 | 18.4 | ||||
Theoretical Shot Volume | cm^3 | 113 | 154 | 201 | ||||
SHOW WEIGHT(PS) | g | 103 | 140 | 183 | ||||
INJECTION PRESSURE | Mpa | 249 | 183 | 140 | ||||
THEORETICAL INJECTION RATE(PS) | g/s | 67.5 | 91.8 | 120 | ||||
PLASTICISING CAPACITY | g/s | 8.3 | 12.5 | 18 | ||||
SCREW TORQUE | N.m | 510 | ||||||
MAX.SCREW ROTATE SPEED | r/min | 260 | ||||||
INJECTION STROKE | mm | 160 | ||||||
CLAMPING UNIT | ||||||||
ITEM | UNIT | VALUE | ||||||
MAX.CLAMPING FORCE | KN | 950 | ||||||
MAX.OPENING STROKER | mm | 340 | ||||||
SPACE BETWEEN TIE BARS | mm | 360×360 | ||||||
MOULD HEIGHT | mm | 135~380 | ||||||
MAX.DAYLIGHT | mm | 720 | ||||||
EJECTOR FORCE | kn | 25.4 | ||||||
EJECTOR STROKE | mm | 85 | ||||||
EJECTOR QUANTITY | pc | 5 | ||||||
OTHER | ||||||||
ITEM | UNIT | VALUE | ||||||
PUMP MOTOR POWER | KW | 11 | ||||||
PUMP PRESSURE | Mpa | 16 | ||||||
HEATING POWER | KW | 7.3 | ||||||
HEATING ZONE | 4 | |||||||
SIZE | m | 4.25×1.2×1.8 | ||||||
NET WEIGHT | t | 3.2 | ||||||
OIL TANK CAPACITY | L | 260 | ||||||
INTERNATIONAL DESIGNATION | 950-280 | |||||||
Main Features
1) Equipped with optimized hydraulic system, the injection speed is greatly improved
2)Servo driver control of injection molding machine is not only acurate but also fast,and the repeatability of the products high as well.
3)The high rigidity clamping structure can meet the requirement of high speed and high pressure, which is beneficial to prolong the life of the mould and greatly improve the precision of the products.
Product Application
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Packing & Delivery
Packaging | ||
Size | 425(L) * 120(W) * 180 (D) | |
Weight | 3.2 T | |
Packaging Details | The normal package is wooden pallet. we will use pe film for packing or pack it according to customers special request. | |
Contact us
Related Products
Ex-factory price
98.8% Response Rate
Free accessories
98.8% Response Rate
20 years of professional service team
98.8% Response Rate
Certifications
FAQ
1.Q:Are you a factory or trading company?
A: Industry and Trade Integration, we supply the factory price with good quality, welcome to visit !
2.Q:How does your factory do regarding quality control?
A:"Quality is priority. we always attach great importance to quality controlling from the very beginning to the very end and we have a dedicated quality control department.
3.Q:What are your normal lead times?
A:Our company typical lead times range from 25-35days after receipt of order.We also have independent venues and engineers to deal with more urgent orders, which can be shipped within 2 weeks.
4.Q:About the price?
A:We will estimate the cost and provide you with the best price. We can guarantee you the best product quality and after-sales service at the same price. Old customers will enjoy more price concessions.
5.Q:How is your machine different from other businesses？
A:We have optimized the overall layout of each part of the machine to make the machine run smoothly and have a longer service life. The fine parts have exclusive marks, which makes it more convenient for customers to replace parts and use.
6.Q:Where is your factory located? How can I visit there?
A: Our factory is located in Shenzhou Machinery, No. 22 Zhenbei Road, Fenghuang Town, Zhangjiagang City China.All our clients,from home or abroad, are warmly welcome to visit us!
A: Industry and Trade Integration, we supply the factory price with good quality, welcome to visit !
2.Q:How does your factory do regarding quality control?
A:"Quality is priority. we always attach great importance to quality controlling from the very beginning to the very end and we have a dedicated quality control department.
3.Q:What are your normal lead times?
A:Our company typical lead times range from 25-35days after receipt of order.We also have independent venues and engineers to deal with more urgent orders, which can be shipped within 2 weeks.
4.Q:About the price?
A:We will estimate the cost and provide you with the best price. We can guarantee you the best product quality and after-sales service at the same price. Old customers will enjoy more price concessions.
5.Q:How is your machine different from other businesses？
A:We have optimized the overall layout of each part of the machine to make the machine run smoothly and have a longer service life. The fine parts have exclusive marks, which makes it more convenient for customers to replace parts and use.
6.Q:Where is your factory located? How can I visit there?
A: Our factory is located in Shenzhou Machinery, No. 22 Zhenbei Road, Fenghuang Town, Zhangjiagang City China.All our clients,from home or abroad, are warmly welcome to visit us!
You are welcome to send us samples, we will customize high-quality machines for you!Best wishes for you!
