4/8-CH Compact CWDM Mux/Demux module(4/8-CH CCWDM)
USD $1 - $100
/ Piece
10 Pieces(Min.Order)
- 40000 Piece / Pieces per Month
- Shenzhen
- T/T L/C D/P D/A Credit Card PayPal Cash Escrow Other
You May Like
Product Details
| Brand Name | flyin | Place of Origin | China | |
| Model Number | CCWDM |
Product Description
Number of Channels：
4 Channel 8 Channel X Channel Specify
Express Port：
1310 (+/-50nm) 1260~1458nm Specify
1st Channel：
1270nm 1470nm 1490nm 1610nm Special
Fiber Type：
250μm 900μm
Fiber Length：
0.5m 1m 2m Specify
In/Out Connector：
None FC/APC FC/UPC SC/APC SC/UPC LC/APC LC/UPC ST MU
Package Type：
L44xW28xH6mm L53.8xW28xH8mm
| Features | Applications |
| Low Insertion Loss | Line Monitoring |
| Wide Passband | WDM Network |
| High Channel Isolation | Telecommunication |
| High Stability and reliability | Cellular Application |
| Epoxy free on optical path | Fiber Optical Amplifier |
| Compact size | Access Network |
| Parameter | Specification | |||||
| Channel Number (CH) | 4 | 8 | 8(+E1) | 8(+E2) | ||
| Center Wavelength（nm） | 1270, 1290…1610 or 1271, 1291…1611 | |||||
| Passband（nm） | Channels (Min.) | +/-6.5 | ||||
| Upgrade port(Min.) | / | 1310+/-50 | 1260~1458 | |||
| Isolation（dB） | Mux | Adjacent (Min.) | 30 | |||
| Non-adjacent (Min.) | 45 | |||||
| Upgrade Por?(Min.) | 15 | |||||
| Demux | Adjacent (Min.) | 30 | ||||
| Non-adjacent (Min.) | 45 | |||||
| Upgrade Por?(Min.) | 15 | |||||
| Insertion Loss（dB） | Channels (Max.) | 1.0 | 1.5 | 1.5 | 1.5 | |
| Upgrade Por?(Max.) | / | / | 1.2 | 1.2 | ||
| Maximum Ripple in Passband（dB） | 0.5 | |||||
| Min. Directivity (dB)? | 55 | |||||
| Maximum?Polarization Dependent Loss?(dB)? | ≤0.2 | |||||
| Maximum?Polarization Mode Dispersion (ps） | 0.10(GD) | |||||
| Min. Return Loss（dB） | 50 | |||||
| Fiber Type? | Corning SMF-28e,900um Loose Tube | |||||
| Fiber Length (m） | 1.0+/-0.1 | |||||
| Maximum Power Handling (mW) | 500 | |||||
| Opterating Temperature (℃) | -10~+70 | |||||
| Storage Temperature (℃) | -40~+85 | |||||
| Package dimension (mm) | Package A: (L)44.0x(W)28x(H)6.0 ??Package B: (L)53.8x(W)28x(H)8.0 | |||||
