Taian High Quality Common Rail Injector Pump Test Bench CRS825C, CRS-825C HEUI,EUI/EUP Test Performance Optional Add
- T/T Credit Card
You May Like
-
Auto Testing Machine CRS-708C Diesel Fuel Injection Pump Test Bench EPS708 Made in China Injector Test Bench
-
Diesel Injector Tester Calibration Machine CRS-708C Common Rail Tester CRS708C Injector Test Bench
-
CRS-708C High Quality CRDI/ EUI/EUP /HEUI Injector Test Bench EPS708 Common Rail Tester Fuel Pump Test Bench CR708 QR-coding BIP
-
Common Rail Injector Test Bench CRS-825C Diesel Fuel Injection Pump Test Bench EPS918,CR918/CR825 Optional Add HEUI and EUI/EUP
-
Injection Pump Test Machine CRS-825C Common Rail Injector Test Bench EPS708 China Optional HEUI C7/C9 EUI/EUP
-
Good Feedback CRDI Tester CRS-205 Piezo Injector Test Bench EPS205 China Made Injector Nozzle Tester Optional Add QR-coding
Product Description
CRS-825C common rail test bench with creating QR code
Can test common rail pump,injector and piezo injector
Huge number of standard databases
Can remote control and data upgrade
Product Description
| Common rail test bench | CRS-825C |
CRS-825C test bench can test common rail pump & injector & piezo injector.
It test by flow sensor with more precise and stable measurement.
It can add EUI/EUP, HEUI,CART 320D common rail pump,CART actuating pump test system to this machine(optional add).
The data is obtained by computer.
19" LCD screen display.
CRS-825C test bench auxiliary tools
Characteristic
1.Main drive adopts the speed change by frequency change.
2.Controlled by industrial computer in real time, Windows operating system.
Fulfill the remote assistance by internet and make the maintenance easy to operate.
3.Common rail injector oil quantity is measured by imported high precise sensor and displayed on 19 LCD .
4.Drive signal can be adjusted
5.Percentag e of drive signal can be adjusted.
6.Rail pressure can be tested in real time and controlled automatically, it contains the high-pressure protection function.
7.Data can be searched, printed and made into database.
8.Pulse and frequency of the injector drive signal can be adjusted.
9.injection time can be setted.
10.Protection function of short-circuit.
11.Oil temperature is controlled by forced-cooling system.
12.Plexiglass protective door, easy operation, safe protection.
13.Measure the flux of common rail pump by flow meter sensor.
Functions
|
Common Rail Injector |
Common Rail Pump |
|
1. test brands: all common rail injector |
1. test brands: all common rail pump |
|
2. test 1 piece of injectors at a time. |
2. test the sealing of common rail pump. |
|
3. test the max. oil quantity of high-pressure common rail injector. |
3. test the internal pressure of common rail pump. |
|
4. test the cranking oil quantity of high-pressure common rail injector. |
4. test the proportional electromagnetic valve of common rail pump. |
|
5. test the backflow oil quantity of high-pressure common rail injector. |
5. test the input pressure of common rail pump. |
|
6. test the average oil quantity of high-pressure common rail injector. |
6. test the flux of common rail pump. |
|
7. set the high-pressure common rail injector's injection state and oil quantity measurement. |
7. measure the rail pressure in real time. |
|
8. Data can be searched, printed and made into database. |
8. Data can be searched, printed and made into database. |
Technical Parameters
|
Injection testing frequency |
50~3000 rpm |
|
Pulse width |
0.1~200 ms |
|
Continuous injection times |
0~1000 |
|
Fuel temperature |
40±2°C |
|
Supply oil quantity of common rail injector |
0~200cc/min 0.5% |
|
Rail high pressure |
0~2200 bar |
|
Test oil filtered precision |
5μ |
|
Input power |
380V/50hz/3phase or 220V/60hz/3phase |
|
Rotation speed |
100~3000RPM |
|
Oil tank capacity |
60L |
|
Flywheel inertia’s moment |
0.8KG.M2 |
|
Center height |
125MM |
|
Output power |
15KW |
|
Overall dimension(MM) |
2200×900×1700 |
|
Weight |
1100kg |
