OF Series Outdoor Commercial Advertising LED Display

FOB Price

USD $500 - $2000 / Piece

2000 Pieces(Min.Order)

Supply Ability 2000 Piece / Pieces per Month
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

As the top reliable LED display manufacturer, LEDFUL has 3~5 years warranty on outdoor advertising LED display screen. We offer high quality LED stage screens for sale for customers’ different requirements.

Partner

Specification

OF/OFR	OF2.5	OF3	OF3.076	OF3.91	OF4	OF4.81	OF5
Pixel Pitch(mm)	2.5	3	3.08	3.91	4.00	4.81	5.00
Pixel Matrix Per Sq.m	160000	111111	105680	65436	62500	62500	40000
Pixel Configuration	SMD1415	SMD1415	SMD1415	SMD1921	SMD1921	SMD1921	SMD1921
Brightness (nits)	5000	1800	5000	4000	5000 5500	4000	5500
Scan	1/16	1/16	1/13	1/16	1/10 / 1/8	1/13	1/8
Module Dimension	160x160mm	192x192mm	320x160mm	250x250mm	320x160mm /256x128mm	250x250mm	320x160mm
Cabinet Dimension	960x960mm （Cabinet size can be changed according to module size）
Cabinet Weight	46kg / 101lb (Iron)	46kg / 101lb (Iron)	45kg / 99lb (Iron)	44kg / 97lb (Iron)	44kg / 97lb (Iron)	43kg / 95lb (Iron)	43kg / 95lb (Iron)
Power Con. (Max / Avg)	900/ 180 w/sq.m	900/ 180 w/sq.m	900/ 180 w/sq.m	900/ 180 w/sq.m	900/ 180 w/sq.m	900/ 180 w/sq.m	900/ 180 w/sq.m
IP Rate	IP65
Service Access	Rear
Refresh Rate (HZ)	>1920
Grey Scale (bit)	16bit
Viewing Angle (H/V)	140/140
Input Voltage (AC)	110V/240V

OF/OFR	OF6	OF6.6	OF8	OF10S	O10D	OF16S	OF16D
Pixel Pitch(mm)	6	6.67	8	10	10.00	16	16.00
Pixel Matrix Per Sq.m	27777	22500	15625	10000	10000	8000	10000
Pixel Configuration	SMD3535	SMD2727	SMD3535	SMD3535	DIP346	SMD3535	DIP346
Brightness (nits)	5500	5500	6500	6500	10000	8000	10000
Scan	1/8	1/6	1/3	1/2	1/2	1/1	1/1
Module Dimension	192x192mm	320x160mm	320x160mm	320x160mm	320x160mm	256x256mm	256x256mm
Cabinet Dimension	960x960mm （Cabinet size can be changed according to module size）
Cabinet Weight	42kg / 93lb (Iron)	42kg / 93lb (Iron)	41kg / 90lb (Iron)	40kg / 88lb (Iron)	40kg / 88lb (Iron)	46kg / 101lb (Iron)	46kg / 101lb (Iron)
Power Con. (Max / Avg)	900/ 180 w/sq.m	900/ 180 w/sq.m	900/ 180 w/sq.m	900/ 180 w/sq.m	900/ 180 w/sq.m	900/ 180 w/sq.m	900/ 180 w/sq.m
IP Rate	IP65
Service Access	Rear
Refresh Rate (HZ)	>1920
Grey Scale (bit)	16bit
Viewing Angle (H/V)	140/140
Input Voltage (AC)	110V/240V

We provide a wide range of Outdoor Commercial Advertising LED Display products, which including LED commercial advertising display screen, commercial advertising LED display, outdoor LED advertising display, large LED advertising screens, large advertising screens, large outdoor advertising screen, LED advertising display screen, etc. We also offer a competitive price for you.
