4-20mA 2-10V Signal Source PWM Pulse Sine Wave WFSGS-06 Handheld Signal Generator Module

4-20mA 2-10V Signal Source PWM Pulse Sine Wave WFSGS-06 Handheld Signal Generator Module

Description:
Handheld multifunctional signal generator enables PWM, pulse, signal source, sine wave, and triangle wave.

Product Parameters:
- Charging and Power Supply Voltage: USB 5V (when built-in battery is fully charged, it can work continuously for 8 hours, the battery capacity is 1000mAh)
- Product Functions: PWM mode, pulse mode, signal source mode, sine wave mode
- PWM Mode: voltage, frequency, and duty cycle are all adjustable, with frequency accuracy up to 0.1%; voltage range: 1-24V, frequency range: 1-150KHZ, duty cycle range: 0-100%
- Pulse Mode: initial delay time T0: 0-60S, high level time T1: 0-60S, low level time T2: 0-60S, number of pulses P-N:1-99999999, resolution: 0.001S
- Signal source mode: voltage source 2-10V adjustable, current source 4-20mA adjustable
- Sine wave mode: 1-999999HZ adjustable (Triangle wave adjustable range is the same)
- Signal load capacity: the maximum output current is 20mA (Note: this product is a signal source, which cannot directly drive high-power loads)
- Environment temperature: -10 to 70℃
- Dimensions: 92 x 70 x 28mm
- Weight: 105g

Package Included:
- 1 x Set of Signal Generator

Detail photo
