stand-alone 2 axis CNC controller for lathe CNC controller
- T/T Credit Card
You May Like
-
Perfectly 3 axis CNC lathe controller instead of GSK/Fanuc cnc controller
-
with professional user manual SZGH-CNC990TDb-2 Two Axis CNC Lathe & Turning Controller
-
SZGH low cost cnc stepper motor controller 4 axis cnc milling panel
-
SZGH-CNC1000TDb-2 2 Axis Lathe and Turning CNC Controller
-
Updated 2 axis CNC threading lathe controller similar as GSK cnc control system
-
homemade 3 axis CNC milling controller for hobby wood router machine centre & parts cnc mill vmc control panel szgh
Product Description
Features:
1)Adopt ARM11 and DSP, FPGA and hardware interpolation technology .
2)The max speed is 300m/min, feeding speed is 150 m/min
3)128Mb Memory, 100Mb user store room.
4)800x600 8.4 inch real color LCD displayer.
5)Touch screen main and sub panel.
6)High anti-jamming switch power.
7)USB movable U disc copy interface.
8)RS232 interface.
9)Spindle servo speed control/spindle frequency convenient speed control.
10)max screw processing thread pitch is 1000MM
11) Support Position Feedback & Linear Scale
Technical specification:
•X,Z two axis lathe
•liner, circular, spiral line interpolation instruction.
•min input unit:0.001mm.
•program size range:± 99999.999.
•Feeding speed:0.001-10m/min
•Max speed: is 20 m/min
• length Compensation
•tool radius automatic compensation
•RS232 and U flash connection port
•Spindle servo speed control/spindle frequency convenient speed control.
•max screw processing thread pitch is 1000MM
•I/O 40X24 input and output
System operation condition:
1) Power supplying
AC 220V(+10%/-15%), Frequency 50Hz±2%. power:≤ 200W.
Note:it must use isolation transform to supply power,first input:380V
2) Climate condition
operation condition:temperature 0~45°C,relative moisture 40-80%.
storage & transportation condition:temperature -40~55°C,relative moisture <93%(40°C).
atmosphere pressure:86-106kpa.
3) operation environment :
No excessive flour dust, no acid, no alkali gas and explosive gas, no strong electromagnetic interference.
Application:
Mini-type special lathe machinery,CNC lathe machinery,hardware processing industry,and automatic equipment,etc.
1.Industrial packing: plastic bag +foam boxes+ carton +wooden pallets
2.Commercial packing: plastic bag+ foam boxes + carton
3.As the clients’ requirement
Delivery Detail: Normally ready goods and stock within 2-5days
• Certified actual products - We have a zero-tolerance policy for asset recovery vendors.
• Lowest package prices -Always offer lower price than other companies.
• Professional technical engineer team- possible fastest response and support to client’ application demand.
• Quality guarantee – Free, one-years warranty and life-long maintenance. Any quality problem, SZGH promise to refund.
• Fast, professional and reliable International delivery – flexible and low cost delivery solution for clients.
• Free payment mode by T/T, L/C, western union and Paypal can be available.
We can provide total control system!
About our company:
Website in Alibaba: http://ghauto.en.china.cn/
Official Website: /
Shenzhen Guanhong Automation CO.,LTD (Formerly known as 'Shenzhen Guanhong Automation Technology Co.,Limited(Built in 19 November 2010)') is one of the leading CNC & automatic company in China, specialized in designing projects, marketing, and oversea trading, having extensive experience in CNC package solution, Our focus has been on providing the high quality of Lathe CNC system, Milling CNC system, Engraving CNC system, AC servo motor & driver, TECO servo motor&driver, Stepper motor & driver, Closed stepper motor &driver, Gear reducer.
We has professional technical team, strictly product test for high quality guarantee, very competitive quotation, specially we has flexible and convenient payment mode and low cost delivery solution for clients.
Our company tenet “Quality is the life of enterprise “, Your satisfy is our greatest achievement.
