Factory Price Yogurt Mixer Machine 500 l Mini Yogurt Production Line
                            Negotiable


                                                1 (Min. Order)

                    - T/T Credit Card

You May Like
-


Commercial Yogurt Processing Machine Small Scale Yogurt Production Line
 -


Industrial Soya Yogurt Making Machines Dairy Milk Yogurt Production Line
 -


Food Grade Yogurt Making Machine Commercial Dairy Yogurt Production Line
 -


High Quality Machine to Make Yogurt Integrated Yogurt Production Line
 -


Professional Fruit Yogurt Machine Complete Yogurt Production Line
 -


Wholesale Yogurt Maker Machine Commercial Yogurt Production Line

Product Description
Product Description





Cooling Tank
Material: SUS304
Power supply: 380v/50Hz
Total power: 2Kw
Cooling capacity: 5000 kcal/hour
Sheet thickness: inner 2mm middle1mm
outer1.2mm
Installation size: 1700*1100*1950mm
Refrigeration medium: R22
Thermal insulation performance: ≤1℃/3H Compressor:2P
Motor power/quantity: 0.75kw/1
Insulation material/thickness: polyurethane foam/50mm
Material inlet and outlet diameter: Φ32mm/
Φ38mm

Duplex filter
Filtering capacity: 5t/h
Applicable temperature: ≤120℃
Filter aperture: 200 mesh
Working pressure: ≤0.2MPa
Filter material: 304 stainless steel
Filtration accuracy: 200 (mesh/in)

Preheating tank
Material: SUS304
Power supply: 380v 50Hz
Power: 9kw
Thickness of heavy plate: inner 2mm middle 2mm outer 1.2mm
Installation size: 1020*870*1530mm
Power of stirring motor: 0.55kw
Stirring speed: 36r/min
Working pressure: 0.09 Mpa
Maximum temperature: the boiling point of the liquid at the local pressure
Material inlet and outlet diameter: Φ32mm/Φ38mm

Homogenizer
Output: 200L/H
Maximum pressure: 25Mpa
Motor power: 4kw
Dimensions: 990*600*850mm
Whole machine weight: 600kg
Pump body material: 1Cr18Ni9Ti
Lubrication method: splash lubrication
Gear form: hardened helical gear
Crankshaft material: 45# steel, surface hardened processing
Plunger material: 9Cr18
Plunger diameter and frequency: 20mm, about 210 times/min
Plunger sealing material: V-shaped cloth clip ring
Check valve structure: cone valve
Check valve material: special steel treatment
Homogeneous rod and seat material: special hard alloy

Pasteurizer
Material: SUS304
Power supply: 380v 50Hz
Power: 9kw
Thickness of heavy plate: inner 2mm, middle 2mm, outer 1.2mm
Installation size: 1020*870*1530
Stirring motor: 0.55kw
Stirring speed: 36r/min
Working pressure: 0.09 Mpa
Maximum temperature: the boiling point of the liquid at the local pressure
Material inlet and outlet diameter: Φ32mm/Φ38mm

Fermenter
Material: SUS304
Power supply: 380v 50Hz
Power: 9kw
Thickness of heavy plate: inner 2mm, middle 2mm, outer 1.2mm
Installation size: 1400*1400*1950mm
Stirring motor: 0.55kw
Stirring speed: 36r/min
Working pressure: 0.09 Mpa
Maximum temperature: the boiling point of the liquid at the local pressure
Material inlet and outlet diameter: Φ32mm/Φ38mm

Filling Machine
Material: SUS304
Working method: continuous work
Filling method: automatic filling
Equipment size: 1300*1300*1750mm

Air Compressor
Power: 7.5kw
Wooden box size:1240*500*1060mm

Acid/Alkali/Water Tank
Water tank capacity: 500L
Alkali tank capacity: 500L
Acid tank capacity: 500L
Pump power: 1.5kw
Equipment weight: 500kg
Dimensions: 4000*900*2300mm

Pump
Voltage: 380V/three-phase/50hz
Flow rate: 1T/H
Import and export of materials: Φ38mm
Power: 0.75kw

Pipe Valve Base
Material:SUS304
Thickness: 2mm
Mirror polished inside and outside

Final Product
All kinds of yogurt











Company Profile

Luohe Orange Mechanical Equipment Co., Ltd. (Orange) is an integrated industrial enterprise located in Henan Province, China. Our company is specialized in the production, processing and sales of mechanical & electric equipment.
Our company covers 35,000 square meters and the fixed asset is RMB10 million Yuan. There are over 200 employees, more than 30 technicians, and over 100 sets of various manufacturing equipment, including: large scale forcing press machine, digital lathe, digital wire-electrode cutting equipment, various processing machines and equipment, etc. Our company owns national patents and proprietary technology with independent intellectual property right. We have a full set of manufacturing techniques and complete quality control devices.

Orange has a professional team of engineers with rich experience in the design, production and inspection. We provide good after-sales service to ensure the successful operation of our equipment for the optimized benefits of customers in the shortest production period and with the minimum investment. We know client's requirements and how low-cost sourcing can help clients strategically and maintain their competitiveness in market.

Orange people with full vitality and energy expect to be your loyal partner and support you to achieve success.



If you are interested in,please help to contact as below informatrion:
Sherry zhang (sales manager)
Luohe Orange Mechanical Equipment Co.,Ltd
Mobile/wechat/whatsapp
+86-15939556928
QQ:2869071805 Skype:sales02-orange;
E: sales02@orangecoltd.com;

FAQ
Q: What vegetables are used for the vegetable and fruit cleaning production line?
A: The air bubble cleaning production line is suitable for the cleaning of fruits and leafy vegetables. The brush cleaning machine is suitable for the harder vegetables.
Q: Which machines are included in the fruit and vegetable washing line equipment?
A: Air bubble cleaning machine, brush cleaning machine, hair roller cleaning machine, air dryer, packing machine.
Q: What is the market for fruit and vegetable cleaning lines?
A: The market for fruit and vegetable cleaning lines is very good, the application range is very wide, and it have a lot of profit.
Q: Are you manufacturer or distributor?
A: We are the experienced manufacturer and exporter. We own a technical team comprised of over-average experts in R&D and innovation. Notably, we own high-level factories and cooperating factories who can offer efficient manufacturing and high-end products when dealing with bulk order.
Q: How do I know about details and quality of your machine?
A: First, we have product brochures covering all details including parameter, material, output, etc. of most of our production lines; secondly, we can provide you with videos filmed on-site with details about working process and how mechanical parts works during operation; at last, you are warmly welcomed for on-site inspection at our factories.
Q: Why choose us?
A: We have dedicated in the machinery manufactory industry for more than 8 years with rare negative response. We are time proven-- client’s response and comments is the most validate evidence.
