Neodymium Magnets

Neodymium permanent magnets (also called ndfeb permanent magnets, Neo magnets) are consisted of Nd (neodymium), Fe (Ferrum), B (boron), and other elements like Dy (dysprosium) and Ti (Titanium). As part of the permanent magnet family, they are the latest generation of rare earth magnets. Thin neodymium magnets, mini neodymium magnets are extremely super strong magnets commercially available in the world, their pull force are quite strong compared to their own size, they have high magnetic remanence, high energy product and relative good coercive, due to these advantages, they are the most widely used magnets today.

As a neodymium magnet suppliers    in China, RiSheng has various types of neodymium magnets for sale, in our online shops and physical stores, with competitive price per kg, very cost effective. In terms of the size, our factory supplies not only the small series— paper thin, micro, tiny, mini, but also the big ones—large, huge, giant monster. Considering practical applications, we provide customized neodymium magnets. They are of different shapes: arc, rod, bar, ball, ring, disc, flat, block, sphere, eclipse, curved, bonded, rectangular, cylindrical, with countersunk holes; and are for different purposes and industrial uses: for cutting, drilling, grinding, machining, for therapy, water meter, etc. Some of them can be sintered, silicone coated, some can be made super strong, adhesive, waterproof. For the convinience of our customers, Risheng has already prepared relevant pdf files and videos about neodymium magnets. Contact us immediately, get cheaper price with best service.

Types Of Neodymium Magnets

Permanent Magnets

The Permanent Magnet

Permanent Magnet Materials

Permanent Magnetism

Most Powerful Permanent Magnet

Making A Permanent Magnet

Rare Earth Magnet Strips

Rare Earth Permanent Magnet

Iron Permanent Magnet

Powerful Rare Earth Magnets

Grades Of Neodymium Magnets

We can manufacture and supply all the grades from energy product 35MGOe to 52MGoe and from N series to AH series.

Demagnetization Curves Of Neodymium Magnets

As one of the most professional magnet manufacturers, we list the performance of the highest grades with different series when demagnetization.

Physical Properties Of Neodymium Magnets

A few main physical properties are listed, like density, curie temperature, etc.

Sizes & Tolerance Of Neodymium Magnets

We can produce different shapes, like a disc, cylinder, ring, arc segment, and custom complicated shapes, a wide range of sizes are possible with a few limits.

The standard tolerances are generally +/-0.1mm, while slightly varies depending on how big the size is.

Magnetization Of Neodymium Magnets

All Neodymium magnets are anisotropic and oriented with a preferred direction during production, they can only be magnetized thru the oriented direction. Disc/cylinder/ring magnets are axially or diametrically magnetized, block magnets are magnetized along one side of three sides, arc segment magnets are generally diametrically magnetized.

Surface Coatings Of Neodymium Magnets

The corrosion resistance of Neodymium magnets is considered very poor, a surface coating will be necessary, the most common coatings are NiCuNi, Zn, Black Epoxy, Teflon/PTFE, Rubber/Plastic.

Manufacturing Method Of Neodymium Magnets

Neodymium magnets are made by a sophisticated process using very advanced metallurgical methods, the main process is Rare earth raw materials - Quick curing - Strip casting - Hydrogen decrepitation - Milling - Pressing - Sintering - BH curve testing - Machining - Plating - Magnetizing - Packaging.

Applications Of Neodymium Magnets

Neodymium magnets are widely used for industrial, technical, commercial, and consumer applications, the most common applications are motors/generators, sensors, audio equipment, holding/lifting systems, magnetic bearings, hard disc drives, levitation devices, magnetically coupled pumps, medical devices, magnetic separators, packaging closures, commercial signage/display.
