Product Description
GYFTY ADSS without yarn no metallic bury optic cable fiber optic 8 12 24 core micro duct MDPE HDPE sheath multi tube
We are 22 years fiber optic cable manufactory!
Welcome to go to the factory tour!
We focus on the quality of the fiber optic cable!
Send a message to us can get free samples.


Single-Jacket, Non-Armored Cables are designed for campus backbones installations.
The loose tube design provides stable and highly reliable transmission parameters for a variety of voice, data, video and imaging applications.
These cables also provide high-fiber density within a given cable diameter while allowing flexibility to suit many system configurations.
The construction provides additional crush a high-strength ripcord under the armor for easy stripping.
Gel-free means the cables are fully water blocked using craft-friendly, water-swellable materials which make cable access simple and require no cleanup.
The flexible, craft-friendly buffer tubes are easy to route enclosures, and the SZ-stranded, loose tube design isolates fibers from installation and environmental rigors while allowing easy mid-span access.
These cables have a medium density polyethylene jacket that is rugged, durable and easy to strip.

| G.652 | G.655 | 50/125μm | 62.5/125μm | ||
|
 Attenuation (+20℃)  |
@850nm | ≤3.0dB/km | ≤3.0dB/km | ||
| @1300nm | ≤1.0dB/km | ≤1.0dB/km | |||
| @1310nm | ≤0.36dB/km | ||||
| @1550nm | ≤0.22dB/km | ≤0.23dB/km | |||
|
 Bandwidht (Class A)  |
@850 | ≥500MHZ·km | ≥500MHZ·km | ||
| @1300 | ≥1000MHZ·km | ≥600MHZ·km | |||
|
 Numerical Aperture  |
0.200±0.015NA | 0.275±0.015NA | |||
| Cable Cut-off Wavelengthλcc |
 ≤1260nm  |
≤1480nm | |||
Storage/Operating Temperature: -40°C to + 70°C
Features
    Good mechanical and temperature performance
· High strength loose tube that is hydrolysis resistant
· Special tube filling compound ensure critical protection of fiber
· Crush resistance and flexibility
· PE/LSZH sheath protects the cable from ultraviolet radiation



1. Are you the real manufacturer?
Yes. We are the real manufacturer with 22 years’ history.
2. How many years have you been in the field of fiber optics?
Since 1999.
3. Can you accept small order?
Yes, small order is available. We support new projects of our customers as we know business is always from small order.
4. What is your warranty period?
25 years for fiber optic cable
5. Which kind of certification you have?
ISO9001, SGS, UL,RoHS.
6. What is your delivery time?
Usually within 2-3 working days
7.What about your annual production capacity?
Outdoor/Indoor Fiber Optic Cable, our annual output is 8,000,000 KM;
FTTH/FTTX/FTTA Cable, it is 6,000,000 KM per year;
Patch Cord/Pigtails, it is 12,400,000 Pieces per year.
8. What is your payment way?
T/T, L/C, Western Union, and Paypal, etc
9. Can you supply customized products and logo?
-Yes. We supply OEM&ODM service. You can send us your drawing.
