Chinese Factory Lan Cable CAT5e UTP/FTP/SFTP Copper Wire With LSZH Certification Cable Price

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Lan cable CAT5e UTP/FTP/SFTP pure copper wire with LSZH certification/cat5 cable price per meter

The specification of cable

1.Conductor:
material:   solid or stranded copper (Copper Clad Aluminum, Copper Clad Steel, Aluminum, CCAM,CA available)
diameter:24AWG,26AWG,28AWG available
construction   1/0.57±0.02mm
2.Insulator
material:    HDPE
thickness:   0.24±0.05mm
diameter:    1.04±0.06mm
color:       optional
elongation rate: Min.300%
tensile strength:   Min.1.22kg/mm2
3.Jacket
material:    PVC
thickness:   average:0.50mm Min. at any point:0.40mm
diameter:    6.3±0.3mm
color:      to your option

elongation rate: Min.125%
tensile strength: Min.1.41kg/mm2

flammability grade: CMX, CM

4.Transmission distance

Cat5		Material	Works (datapass)	Weight (KG)
0.38mm cca+ 0.35mm ccs			80m	5.2
0.4mm cca+0.35mm ccs			100m	5.4
0.4mm	CA		95m	5.4
0.5mm	CA		115m	5.9
0.4mm	CCA+CCS		90m	5.8
0.45mm	CCA+CCS		100m	6.0
0.5mm	CCA+CCS		110m	6.2
0.4mm	CCA		100m	6.1
0.45mm	CCA		110m	6.5
0.5mm	CCA		120m	6.9
0.4mm	CCAU+CCS		140m	7.05
0.5mm	CCAU+CCS		160m	8.65
0.35mm	copper		130m	6.8
0.4mm	Copper		140m	7.1
0.45mm	Copper		150m	7.9
0.5mm	Copper		160m	8.7

5. Standards: CE, UL, ROHS, ISO 9001:2000, SGS verified

6. Application: 100 Base-TX, 100VG-AnyLAN, 1000 Base-T, 155Mbps ATM, 622Mbps ATM, Noisy Environment
7.Electrical function:

1. DC resistance ≤5.8 Ω/100m

2. Resistance imbalance≤2.5%

3. Insulation resistance≥5000MΩ.Km

5. Dielectric strength (DC)

Conductor-conductor 2.5KV/2s

Conductor-shield 6.3KV/2s

The structure of the cable

The electrical charcteristics of cable

Packing &Shipping

Company information

Shenzhen Brother Young Development CO,.Ltd was founded in 2002 and located in Shenzhen, China, owning two factories covering an area of 150000 square meters.Our company enjoys a history of 15 years of making network cable,patch cord cable,multi-pairs telecommunication cable, telephone cable, patch cord, coaxial cable,fiber optic cable, power electric cable,HDMI Cable,USB cable,VGA cable and other relative network accessories.

Production Process of Network cable

Exhibition

Certification
