X3-M50 Push Rod Camera

Wuhan Easy-Sight Technology Co,.Ltd, found in Nov,2000, in Wuhan, Hubei Province, China, is a leading provider of intelligent pipeline solution, which including pipe cleaning, inspection and pipe rehabilitation equipment.

The X3-M50 push rod type pipeline endoscope is composed of three parts: an integrated main controller, a flexible push rod cable reel, and a high-precision pipe camera. The front-end camera of push cameras for pipe inspection is pushed into the pipeline by a flexible push rod cable to image the inside of the pipeline. Preview and record to achieve the purpose of detection.

Push rod camera in pipe inspection is suitable for surveying and testing the interior of residential, small-scale commercial sites, special factories and municipal engineering pipelines, including slender, narrow, and curved pipelines that cannot be accessed by other testing instruments. Its operation is simple, powerful, and widely applicable.

Cable Wheel

Wheel size: 768L*369W*820Hmm

Cable material: Fiberglass rod

Cable length: 60m-120m

Cable diameter:φ9.5mm, 9 cores

Wheel material: Stainless steel

Meter counter & handle-brake

Counter accuracy: 0.1m

Fiberglass color: Yellow

Camera Head

Camera sizw: φ50mm*L107mm

Sensor size: 1/3 inch CCD

View angle: 90°

Manual focus & self-levelling

Camera light: 6pcs highlight LEDs

Resolution: 960TVLine

Glass material :Sapphire glass

Shell material: Aluminum alloy

Scope of focus: 20mm-infinite

Control Box

Work supply: DC 12V

Storage medium: SD card &USB stick(max 256G)

DVR Total pixels: 720X576(D1)

Video record(mp4) & picture snap(jpg)

10 levels digital zoom

Microphone Audio record

Stereo earphone output

Digital clock& digital calendar
