ZKCC Weather Proof Enclosure Type Vacuum Pumping Set
- T/T Credit Card
You May Like
-
Plastic TPU Pillow Tank / 25000L TPV Flexible Tank / Power Transformer Oil Tank
-
Horizontal Carbon Steel Crude Oil Storage Tank
-
Factory Direct Customizable 30000 Liter Diesel Tank for Oil Storage
-
2000L Used Diesel Fuel Oil Storage Tank
-
Horizontal Type Carbon Steel Crude Oil Fuel Diesel Oil Storage Tank
-
Transformer Oil Diesel Fuel Storage Tank, Cooking Oil Large Size Tank Supplier
Product Description
ZKCC Vacuum Pumping System
Application:
It is widely used in the vacuuming process in the production, installation and maintenance of many electric power equipments, like electric power transformer, capacitor etc., and is also used in the technical process of industrial production, such as vacuum drying, vacuum distillation, vacuum wielding, vacuum coating etc.
It is not suitable for the vacuum process for air and gases containing too much powder, water and oxygen as well as explosive, corrosive, poisonous and chemical substances.
Characteristics:
1. The machine adopts special Roots pump and vacuum pump, so the vacuum pumping speed and pressure, are obviously better than
any other devices.
2. Working vacuum range and maximum vacuum degree are superior to other products.
3. It is installed with special vacuum gauge for accurate indication.
4. It adopts automatic vacuum relay for automatic control.
5. Stable and reliable operation, low noise, and easy to move.
Technical Parameter | ZKCC-30 | ZKCC-70 | ZKCC-150 | ZKCC-300 | ZKCC-600 | ZKCC-1200 | |||||
Pumping Speed (L/s) | 30 | 70 | 150 | 300 | 600 | 1200 | |||||
Pumping Speed (m3/h) | 108 | 252 | 540 | 1080 | 2160 | 4320 | |||||
Ultimate partial pressure (Pa) | 5×10-2 | 5×10-2 | 5×10-2 | 3×10-2 | 3×10-2 | 1×10-1 | |||||
Ultimate partial pressure (Torr) | 3.7×10-4 | 3.7×10-4 | 2×10-4 | 2×10-4 | 2×10-4 | 8×10-4 | |||||
Total Electric Power (kw) | 1.85 | 2.6 | 5.2 | 9.5 | 18.5 | 33 | |||||
Main Pump Type | ZJP-30 | ZJP-70 | ZJP-150 | ZJP-300 | ZJP-600 | ZJP-1200 | |||||
Front Stage Pump Type | 2X-8 | 2X-15 | 2X-30 | 2X-75 | 2X-70 x 2 | 2X-70 x 2 | |||||
Wire size of power supply input ≥(mm2) | 1 | 1.5 | 3 | 4 | 6 | 8 | |||||
Power Supply | 50Hz 380V (3phase, 4wire) also can be customized | ||||||||||
Intake connection (mm) | DN50 | DN80 | DN100 | DN160 | DN200 | 250 | |||||
Exhaust connection (mm) | DN34 | DN60 | DN70 | DN70 | DN70 | DN90 | |||||
Overall Dimensions (cm) | 73×46 ×10 | 79×55 ×120 | 105×60 ×135 | 132×78 ×150 | 145×86 ×201 | 150×90 ×230 | |||||
Technical Parameter | ZKCC-30 | ZKCC-70 | ZKCC-150 | ZKCC-300 | ZKCC-600 | ZKCC-1200 | |||||
Pumping Speed (L/s) | 30 | 70 | 150 | 300 | 600 | 1200 | |||||
Pumping Speed (m3/h) | 108 | 252 | 540 | 1080 | 2160 | 4320 | |||||
Ultimate partial pressure (Pa) | 5×10-2 | 5×10-2 | 5×10-2 | 3×10-2 | 3×10-2 | 1×10-1 | |||||
Ultimate partial pressure (Torr) | 3.7×10-4 | 3.7×10-4 | 2×10-4 | 2×10-4 | 2×10-4 | 8×10-4 | |||||
Total Electric Power (kw) | 1.85 | 2.6 | 5.2 | 9.5 | 18.5 | 33 | |||||
Main Pump Type | ZJP-30 | ZJP-70 | ZJP-150 | ZJP-300 | ZJP-600 | ZJP-1200 | |||||
Front Stage Pump Type | 2X-8 | 2X-15 | 2X-30 | 2X-75 | 2X-70 x 2 | 2X-70 x 2 | |||||
Wire size of power supply input ≥(mm2) | 1 | 1.5 | 3 | 4 | 6 | 8 | |||||
Power Supply | 50Hz 380V (3phase, 4wire) also can be customized | ||||||||||
Intake connection (mm) | DN50 | DN80 | DN100 | DN160 | DN200 | 250 | |||||
Exhaust connection (mm) | DN34 | DN60 | DN70 | DN70 | DN70 | DN90 | |||||
Overall Dimensions (cm) | 73×46 ×10 | 79×55 ×120 | 105×60 ×135 | 132×78 ×150 | 145×86 ×201 | 150×90 ×230 | |||||
Located at Chongqing city--a southwest electromechanical manufacturing center as well as national municipality, Chongqing TOP is a professional leading manufacturer and supplier of oil purifiers and various related testers. We consists of departments respectively for technological development, machinery manufacture, instrument manufacture, quality control etc. On basis of mature development and manufacture technology and highly qualified production management team, the products own high quality, easy operation, excellent performance and lone service life.
TOP Oil Purifiers are widespread in the fields of electric power, petrifaction, mineral, shipbuilding, steel construction, bridge, automobile and railway, playing a great role in reducing energy consumption for clients as well as environmental pollution. We provides you with reliable oil purifiers such as transformer oil purifier, turbine oil purification machine, hydraulic oil purifier, lubricating oil filtration machine, fuel oil restoration, oil and water separator, oil regeneration equipment, waste oil recycling equipment etc.
TOP Testers works on the development, production, market, technical and after-sale service for petrochemical analyzers, transformer substation electrical testing equipment and circuit detecting equipment. Main products are water content testers, surface/interfacial tension testers, flash point testers, kinematic viscosity testers, oil acidity testers, insulation oil dielectric strength testers, transformer characteristics testers, relay protection testers, high voltage testing equipment etc.
Honest Team - TOP always honestly treat you and keep faith to make you satisfied with every cooperation with us.
Sincere Communication - TOP sincerely communicate with you to guarantee the provided products to be your ideal ones.
Reliable Quality -TOP own high quality and high performance for every TOP product is under strict quality control and testing.
Service Commitment - TOP bring you prompt, considerate and professional aftersale service and technical support, and explore technology future together.
Certificates
Office & Factory
Main Oil Purification System
Series ZY Portable transformer oil purifier
Series ZYD Double high vacuum transformer oil purifier
Series ZYD-I Double vacuum transformer oil regeneration machine
Series ZYB Multi-function insulating oil regeneration machine
Series TY Turbine oil purification apparatus
Series TYA Lubricating oil/ hydraulic oil purification unit
Series TYB Portable light fuel oil purification machine
Series TYD Vacuum lube oil/hydraulic oil dehydrator
Series TYF Phosphate ester fire-resistance oil purifier
Series PL Plate pressure oil purifier
Series JL Portable oil filtration machine
Series COP Cooking oil purification machine
Series CYS Centrifugal oil purification machine
Series BAM Press filtration system
Series HFD/VFD filter press machine
Series ZKCC Vacuum pumping system
Series EOS Waste Oil Distillation Plant
Our customer site
Test Equipment
Key word: oil purifier, oil filtration, oil purification, oil filter, oil treatment, oil saving, oil recycling, oil processing, oil filtering, energy saving, oil regeneration, oil processor, oil filter, oil process, oil purify, oil regenerating, oil restoration, waste oil disposal, oil reclaimed, oil reclaiming, waste oil management, oil regenerate, oil reconditioned, oil reconstituted, oil restituting, oil recovering, oil recondition, oil filters, oil refinery, oil refiner, oil cleaning, oil recycle, oil reclaiming, oil separating, oil recovery, oil recycle, oil reclamation, oil refinery, oil separator, oil separation, oil purifiers, oil recondition, oil dehydrator, oil water separator, oil dehydration, machine recycling used oils, waste oil filter, oil degasifier, waste engine purifier, oil refinery plant, mini petrol refinery, oil recycling machine, quenching oil filter, moblie oil puruficator, small oil recycling, bdv testing kit, used vegetable oil recycling machine, used vegetable oil recycling machine, mini diesel refinery, mini diesel refinery, mini diesel refinery,karl fischer moisture analyzer, karl fischer moisture analyzer, oil analysis equipment,oil quality analyzer, used engine oil recycling machine, distillation plant, oil processing machine,oil purification, engine oil recycling distillation technology,engine oil recycling machine no chemical, oil refinering, turbine oil conditioner, no additive oil recycling, used engine oil recycling machine, used motor oil recycling machines, auto transformer oil tester, crude oil purification, oil mini refinery, transformer oil testing machine, transformer oil dielectric strength tester, used motor oil recycling machines, oil purifier equipment, oil purifier equipment, transformer oil test equipment, fuel oil purifier, transformer oil gas analysis, transformer turn ratio, oil analysis equipment, oil analysis equipment, transformer oil dielectric strength tester, supplier of cooking oil reuse machine, regeneration machine, dielectric strength meter, ce tester device, oil filtering machine, mobile transformer oil regeneration plant, transformer ratio tester, biodiesel oil pretreatment, oil distillation plant, transformer oil gas chromatography, excellent transformer oil cleaning regeneration, fuel purification plant, oil cleaner, ship waste oil recycle, oil test kit, transformer oil testing kit, recycling oil in engine oil, transformer oil bdv testing result, press filter,waste oil regeneration, transformer test set, transformer test set, lube oil conditioner, lube oil conditioner, insulating oil transformer oil purifier, used motor oil recycling chemical, transformer oil filtration machine, recycling car oil
