New Design TYB Explosion Proof Coalescer and Separator Filter Light Fuel Oil Filtration Machine
- T/T Credit Card
You May Like
-
Transformer Oil Chromatograph (GC-7890MD)
-
New Arrival Explosion Proof Design TYB Series Tyre Pyrolysis Oil Oil Purifier Equipment TYB-Ex-100
-
Transformer Load And No-load Tester TOFT
-
Insulating Oil Tan Delta ( Dielectric Loss) Tester DLT0812
-
Capacitance and Dissipation Factor Tester /Tan Delta Tester CDEF
-
TPJB-III Relaying Protection Tester
Product Description
Series TYB-Ex explosion-proof portable fuel oil purifier
Item | Unit | TYB-Ex-10 | TYB-Ex-20 | TYB-Ex-30 | TYB-Ex-50 | TYB-Ex-80 | TYB-Ex-100 | |||||||
Flow rate | L/min | 10 | 20 | 30 | 50 | 80 | 100 | |||||||
Working pressure | Mpa | ≤0.4 | ||||||||||||
Power supply | / | 380V/50HZ/3Ph 5 wire(as customer’s requirement) | ||||||||||||
Working noise | dB(A) | ≤65～80 | ||||||||||||
Normal working time | h | ≥4000 | ||||||||||||
Continuous working time | h | ≥150 | ||||||||||||
Total electric power | Kw | 1.1 | 1.1 | 1.1 | 1.5 | 2.2 | 3 | |||||||
Weight | kg | 80 | 100 | 120 | 150 | 200 | 220 | |||||||
Index after filtration | Moisture content | ppm | ≤100 | |||||||||||
Filtering accuracy | μm | ≤5(Customerizable) | ||||||||||||
TYB adopts coalescence separation filter which integrates high precision filtration and high efficient demulsification and dehydration into one, and can remove large amount of water without heating. It has the fastest dehydrating speed in domestic. This machine can quickly separate water from oil though the water content reach 50%. The oil cleanness can reach NAS six grade. This machine is used conveniently with go-cart type design. It’s specially suitable for purifying high water content light oil. TYB-Ex series is explosion-proof type. The explosion proof classes are ExdBT4 and ExdCT4 respectively. It can meet requirement in various dangerous environments.
1.ZY series vacuum transformer oil purifier
2.ZYA series vacuum automatic transformer oil purifier
3.ZYB series vacuum transformer oil regeneration purifier
4.ZYD series double-stage vacuum transformer oil purifier
5.ZYD-I series ouble-stage transformer oil regeneration purifier
6.ZYD-M series trailer-mounted transformer oil purifier
7.TY series vacuum turbine oil purifier
8.TYA series vacuum lubricating oil purifier
9.TYB series coalescence-separation oil purifier
10.TYC series vacuum lubricating oil regeneration purifier
11.CYA series centrifugal oil purifier
12.TPR series waste engine oil recycling system
13.PL series plate and frame oil filter press
14.JL series portable oil purifier
15.BZ series transformer oil regeneration device
MOQ | 1 Set |
Trade Terms | EXW, FOB, CIF, CFR |
Payment Terms | T/T, L/C |
Port of Loading | Any Port of China |
Packing Method | Internaional Standard Wooden Case |
Transportation Method | By Sea, By Land, By Air, By Express |
Supply Capability | 100 Sets/Month |
* The warranty period is 24 months from commissioning acceptance date on. After the warranty period is over we provide lifelong maintenance and technical service.
* We guarantee the maintenance time no more than 3 working days and response time within 1 hour.
* We build instrument service profile for our clients to record the product service and maintenance conditions.
* After instruments start service, we will pay follow-ups to collect the service conditions.
Chongqing TOP Oil Purifier Co., Ltd
Located at Chongqing city--a southwest electromechanical manufacturing center as well as national municipality, Chongqing TOP is a professional leading manufacturer and supplier of oil purifiers and various related testers. Our company consists of departments respectively for technological development, machinery manufacture, instrument manufacture and quality control etc.
Welcome to visit our website, welcome your inquiry.
CHONGQING TOP OIL PURIFIER CO.,LTD
Manufacture oil purifiers and supply test equipment.
Add: No. 1, Jianlong N. Rd., Jiulongpo District, Chongqing, China
E: sales5@topoilpurifier.com
Cell: 0086-15523518178 (Whatsapp/Wechat) | Skype: topoilpurifier05
Tel: 0086-23-88901306 | Fax: 0086-23-88901306
;
