TYF-30 Vacuum Fire Resistant Oil Treatment Purifier Machine To Refine Water Gas and Impurity
- T/T Credit Card
You May Like
-
TYF-100 Gold Supplier China Factory Fire Resistant Acidity Oil Purifier Machine
-
TYF-50 High Performance Fire Resistant Acidity Oil Purifier Equipment
-
CE Approval 304 Stainless Steel Automatic PLC Control Fire Resistance Oil Filtration Unit
-
CE Approval Fully Automatic PLC Control Fire Resistance Oil Filtration Unit
-
304 Stainless Steel Dirty Fireresistant Oil Filtration Machine
-
TYF Series Phosphate Ester Fire Resistance Oil Purifier
Product Description


2.Good adaptability of the material to phosphate ester. No leakage or corrosion.
3.Automatic control; work online at low temperature; pure physical treatment and no secondary pollution.
4.It can not only remove free water and gases in the oil efficiently and quickly, but also deeply remove dissolved water and gases
Item | Unit | TYF-10 | TYF 20 | TYF -30 | TYF -50 | TYF-100 | TYF -150 | TYF -200 | TYF -300 | |||||||
Flow rate | L/min | 10 | 20 | 30 | 50 | 100 | 150 | 200 | 300 | |||||||
Working vacuum | Mpa | -0.06 ~- 0.095 | ||||||||||||||
Working pressure | Mpa | ≤0.4 | ||||||||||||||
Temperature | ℃ | 0~100 | ||||||||||||||
Power supply | 380V/50HZ/3Ph 5 wire(as customer’s requirement) | |||||||||||||||
Working noise | dB(A) | ≤65~80 | ||||||||||||||
Working time | H | ≥ 4000 | ||||||||||||||
Continuous working time | H | ≥150 | ||||||||||||||
Working noise | dB(A) | ≤75 | ≤75 | ≤75 | ≤78 | ≤78 | ≤78 | ≤80 | ≤82 | |||||||
Electric heating power | kW | 36 | 40 | 45 | 72 | 80 | 90 | 120 | 135 | |||||||
Total electric power | kW | 38 | 42 | 47 | 75 | 87 | 101 | 135 | 147 | |||||||
Outlet(inlet) caliber | mm | Ф25 | Ф25 | Ф25 | Ф32 | Ф42 | Ф50 | Ф50 | Ф60 | |||||||
Weight | kg | 350 | 380 | 400 | 450 | 550 | 650 | 700 | 750 | |||||||
Size(mm) | L | 1500 | 1500 | 1500 | 1600 | 1750 | 1900 | 1950 | 2100 | |||||||
W | 1000 | 1050 | 1050 | 1150 | 1150 | 1600 | 1600 | 1600 | ||||||||
H | 1600 | 1600 | 1650 | 1700 | 1750 | 1950 | 1950 | 2000 | ||||||||
Water content | PPM | ≤5 | ||||||||||||||
Gas content | % | 0.1 | ||||||||||||||
Particle Size | μm | ≤1(Customerizable) | ||||||||||||||
Acid | mKOH/g | ≤0.05 | ||||||||||||||










Chongqing TOP Oil Purifier Co.,Ltd, established in 2 0 1 2 , is a professional manufacturer engaged in the research, development, production, sale and service of oil purifiers and various related testers.We are located in Chongqing China - a southwest electro mechanical manufacturing center as well as national municipality, which is one of the most well-known oil purifier manufacturers in southwest China. Dedicated to strict quality control and thoughtful customer service, our experienced staff are always available to discuss your requirements and ensure full customer satisfaction. On basis of mature development and manufacture technology and highly qualified production management team, the products own high quality, easy operation, excellent performance and long service life. In addition, Our company has won C E,S G S certificates. Selling well in all cities and provinces around China, our products are also exported to clients in such countries and regions as Australia, Canada, USA, South Africa , Asia etc.. Our company holds the managerial idea that “ Honest treatment,Sincere Communication,Reliable Quality and Service Commitment”, and tries its best to do well at any aspect from each part, each point of procedure of manufacturing to final inspection, packing and shipment. We also welcome O E M and O D M orders. Whether selecting a current product from our catalog or seeking engineering assistance for your application, you can talk to our customer service center about your sourcing requirements.












maintenance and technical service.
* We guarantee the maintenance time no more than 3 working days and response time within 1 hour.
* We build instrument service profile for our clients to record the product service and maintenance conditions.
* After instruments start service, we will pay follow-ups to collect the service conditions.
