Home > Products > PLC splitter > support customization plc splitter abs box 1x2 1x4 1x8 in fiber opti equipment
support customization plc splitter abs box 1x2 1x4 1x8 in fiber opti equipment
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
plc optical splitter 1U 2U 3U 19' rack-mounted low insertion loss high return loss low PDL Fiber Optic PLC Splitter
-
plc optical splitter tray assembly type
-
1/99 2/98 3/97 5/95 10/90 20/80 30/70 40/60 50/50 fiber FBT splitter FBT Coupler
-
support customization ervice 1x8 LGX box type PLC Optical Splitter with sc fiber adapter for ftth
-
1x2 1260~1650nm wavelength lgx box plc fiber optical splitter with sc/upc or sc/apc adapter
-
1x8 SC UPC/APC Mini Fiber PLC Splitter Single Mode With SC Connectors FTTH Optical Mini-module PLC Splitter
Product Description
Product Description
Detailed Images
Parameter | Unit | 1X2 | 1X4 | 1X8 | 1x16 | 1X32 | 1x64 | |||||||||
Fiber Type | / | G.657A1, or customized | ||||||||||||||
Operating Wavelength | nm | 1260~1650 | ||||||||||||||
Insertion Loss | P | Max | dB | 4.0 | 7.0 | 10.4 | 13.5 | 16.8 | 20.5 | |||||||
S | Max | dB | 4.2 | 7.3 | 10.6 | 13.8 | 17.1 | 20.8 | ||||||||
PDL | Max | dB | 0.2 | 0.3 | 0.5 | |||||||||||
Loss Uniformity | Max | dB | 0.6 | 0.8 | 1.0 | 1.4 | 1.6 | 2.0 | ||||||||
Return Loss | Min | dB | 55 | |||||||||||||
Directivety | Min | dB | 55 | |||||||||||||
Operating Temeperature | ℃ | -40~+80 | ||||||||||||||
Storage Temperature | ℃ | -40~+80 | ||||||||||||||
Dimension (LxMxH) | mm | 100x80x10 | 200x80x18 | 141x115x18 | ||||||||||||
Parameter | Unit | 1X2 | 1X4 | 1X8 | 1x16 | 1X32 | 1x64 | |||||||||
Fiber Type | / | G.657A1, or customized | ||||||||||||||
Operating Wavelength | nm | 1260~1650 | ||||||||||||||
Insertion Loss | P | Max | dB | 4.0 | 7.3 | 10.6 | 13.9 | 17.2 | 20.8 | |||||||
S | Max | dB | 4.2 | 7.5 | 11.0 | 14.5 | 17.5 | 21.0 | ||||||||
PDL | Max | dB | 0.2 | 0.3 | 0.5 | |||||||||||
Loss Uniformity | Max | dB | 0.8 | 1.0 | 1.2 | 1.5 | 1.8 | 2.0 | ||||||||
Return Loss | Min | dB | 55 | |||||||||||||
Directivety | Min | dB | 55 | |||||||||||||
Operating Temeperature | ℃ | -40~+80 | ||||||||||||||
Storage Temperature | ℃ | -40~+80 | ||||||||||||||
Dimension (LxMxH) | mm | 100x80x10 | 120x80x18 | 141x115x18 | ||||||||||||
Packing & Delivery
PLC splitter packed in small paper box
the package can also be packed as customer required
small paper box packed in medium paper carton
Q1: When can I get the quotation back?
A:Generally, quotes will be replied within 24 hours or faster(weekends not included), however, a few of days would be taken for special ones.
Q2:How about the cable's quality ?
A: Our factory has dug in this industry for many years and sold to many countries in the world. We are fully compliant with ISO9001: 2008 quality management system, we guarantee that our products are IEC60794 and Telcordia-GR-326-Core standard compliant. We have a series of professional equipment and manufacturing instruments to make sure reliable quality of our products.
Q3: How do l assure that you are a reliable supplier?
A: We are the Assessed Supplier of . Alibaba as the third party to verify our factory and office to confirm we are a real and reliable supplier. If you are willing to verify that through the phone or video, you are welcome at any time.
Q4: Could the OEM be accepted and what's the MOQ?
A: Of course, your customization order is always welcomed. The MOQ Depends on different
