Automatic High Speed Straight Line Box Folder Gluer Packing Machine

Introduction

       ZH-1050 is a multi function model,suitable for card board,EB flute corrugated board,can do two fold,four fold,and bottom lock.This model has correction device and bottom lock device.Can make electrical adjusting.Has UV destroying device and dust remove device for better gluing effect.

Machine Characters

1.Driving by synchronous belt,ensure smooth and accurate running

2.Inverter driving,stable and power saving

3.Use tooth bar adjust(for higher configuration use electric adjust),easy operate

4.Automatic continuous feeding,use multiple belt with vibrating motor,(for higher configuration    use drilled suction belt),to keep the feeding stable.

5.Special three plate prefolding as optional

6.Two upper glue device and two lower glue device ,for different kind gluing.

7.Automatic counting and kicking ,quantity can preset.

8.Conveyer pressure adjustable according to the box to ensure best quality

Technical Parmeters

Configuration

1)Main motor:TECO Taiwan

2)Inverter:Siemens

3)Timing belt and pulley:Optibelt German

4)Bearing:NSK

5)Main axis:Taiwan chorme plated steel bar

6)Wall thickness:20mm tempered

7)Feeding belt:Habasit Switcherland

8)Transfer belt:NITTA Japan

9)Plain belt:NITTA Japan

10)Low voltage apparatus:Omron/Fuji

Optional:Plasma 2 guns 2600$

Delivery : 35 days

Packing : Film packing and loaded in 1*40GP and 1*20 GP Containers, if need with wooden packaging need add 1700$

Payment terms: 1) T/T.20% deposit in advance, and 80% balance before shipped.

Warranty period:12 months

Buyer need to pay travel expenses(ticket),hotel accommodation,food .

Supplier will send one engineer to customer’s factory for installation and training,according 80$ salary every day.

About Factory

Warranty Service:

Machines are new (or unused) and the guarantee period will be given thirteen months from shipment date.

During this period, the seller will offer free maintenance and free spare parts that caused by the machine’s quality, but the buyer must pay the courier cost.

Parts damaged because of mishandling and consumable parts are not covered by any warranty.
