High Quality Welded Mesh Panel Curved Welded Mesh Fence

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

QYM-Welded mesh fence It is an economical version of the panel system, constructed from a welded mesh panel with longitudinal profiles that forms a rigid fence. The fence panel is welded with high quality low carbon steel wire, surface treated by electrostatic polyester powder spray coating over galvanized materials, then connected with post by suitable clips. Due to its simple structure, easy installation, nice appearance, more and more customers regard welded mesh fence as the preferred common protective fence.

Mesh	Wire Thickness	Surface Treatment	Panel Width	Folds NOS.	Height
50x200mm or 55x200mm	4.50mm or 5.00mm	Galvanized and Electrostatic polyester powder coated or PVC coated	2.50m	2	830mm
						2	1030mm
						2	1230mm
						2	1430mm
						3	1630mm
						3	1830mm
						4	2030mm
						4	2230mm
						4	2430mm

* Steel Material:Q195-Q235
* Color:darkgreen(RAL6005),other RAL colors,also available as request uv available.

Mesh	Wire Thickness	Surface Treatment	Panel Width	Folds NOS.	Height
50x200mm and 50x100mm in folds Or 55x200mm and 55x100mm in folds	4.50mm or 5.00mm	Galvanized and Electrostatic polyester Powder coated or PVC coated	2.50m	2	1030mm
						2	1230mm
						3	1530mm
						3	1730mm
						4	2030mm

Profile	Wall Thickness	Surface Treatment	Length	Base Plate	Rainhat
50x50mm	1.50mm - 4.00mm	Galvanized and Electrostatic polyester powder coated	On the basis of panel height	Available	Plastic or Metal
60x60mm	1.50mm - 4.00mm	Galvanized and Electrostatic polyester powder coated	On the basis of panel height	Available	Plastic or Metal

* Steel Material:Q195
* Color:darkgreen(RAL6005),other RAL colors,also available as request uv available.

Profile	Wall Thickness	Surface Treatment	Length	Base Plate	Rainhat
60x40mm	1.50mm - 4.00mm	Galvanized and Electrostatic polyester powder coated	On the basis of panel height	Available	Plastic or Metal
80x40mm	1.50mm - 4.00mm	Galvanized and Electrostatic polyester powder coated	On the basis of panel height	Available	Plastic or Metal

Profile	Wall Thickness	Surface Treatment	Length	Base Plate	Rainhat
50x70mm	1.20mm Or 1.50mm	Galvanized and Electrostatic polyester powder coated	On the basis of panel height	Available	Plastic
60x90mm
70x100mm

Profile	Wall Thickness	Surface Treatment	Length	Base Plate	Rainhat
Φ48	1.50mm - 3.20mm	Galvanized and Electrostatic polyester powder coated	On the basis of panel height	Available	Plastic or Metal
Φ60
Φ75

Variations for post

l In addition to the standard posts many variations are available to accommodate site requirements:
l ? alternative sections
l ? wall fixing plates, cranked posts or base plated
l ? cranked or straight extensions for barbed or razor wire

Company Information

Hebei Qianye Metal Product Co., Ltd is a company engaged in production and exportation of metal fence as well as other metal products, such as airport fence, barb wire, chain link fence, concertina razor wire, double wire fence, euro fence, palisade fence, temporary fence, welded mesh, welded mesh fence, wire mesh, etc. Its registered capital is RMB50, 100, 000(about USD 7,400, 000), covering a land area of 30, 000 square meters.
Service
1>Quality Products:
We follow the policy of Seeking Development through Quality and Establishing Reputation via
Quality Products. We try to meet customers' requirements with excellent quality products.
2>Honest Service:
We offer honest service to customers. We provide products with sincere and excellent service and the most prompt delivery.
3>Innovation:
We have advanced inspection and production equipment and can develop new products to meet the demand of market. We can also accept customized orders. Our strong R&D capability enables us to innovate almost everyday.

Packing & Shipping

1>Panel Packing:
It has soft sponge at the botom of the pallet to avoid the botom fence panel to be damaged by metal pallet.
It has 4 metal corners to keep the pallet be more strong.
It has metal plate under the plastic bandage to avoid the bandage to presure the fence panel.
It has wood plate on the top of pallet to keep the above pallet to de destroyed by the pallet.
2>Post Packing:
The post is covered with plasti cap then packed with plastic flim. Clips packed by set.
3>Accessories:
Plastic bags + carton boxes

FAQ

Q: What's QYM's after service policy?
A: QYM's after service staff will contact you when you received the products, and ask for your comments on the products. Anyissues on QYM's products, please send email or call us. QYM will service you timely with whole-heartedness and profession.

Q: What's the MOQ of QYM's product?
A: Different item has different MOQ. Normally 1X20FCL is preferred, LCL could be negotiable.

Q: How can we get the quotation from QYM?
A: Please send your inquiry to QYM's official email.

Q: How to be QYM's agent, wholeseller or distributor in my country?
A: Please send your company's basic information and application to my email adress. A feedback will be sent to you within 7 working days.
