New Zealand Standard Hot Dipped Galvanized Steel Pipe Used Farm Fence Gates for Sale

1.Material:

Normally Q235 steel pipe and high tensile Chain link steel wire 1000Mpa or on customers' requirement.

2.Surface treatment:hot dip galvanized 250g/m2 or heavy hot dip galvanized 400g-600g/m2 or galfan surface treatment(galfan treatment is more durable and 2-3times life-time longer than galvanized)

Welded wire mesh gates

gate width(m / ft)

vertical braces

gate height
(m)

mesh spacing (mm)

Type A

2.38m / 8'

1

1.17m

100x250mm

TypeB

2.98m / 10'

1

1.17m

100x250mm

Type C

3.58m / 12'

1

1.17m

100x250mm

Type D

4.18m / 14'

2

1.17m

100x250mm

Type E

4.78m / 16'

3

1.17m

100x250mm

Steel pipe farm gates

gate width(m / ft)

vertical braces

gate height
(m)

Horizontal pipe spacing (mm)

Type A

2.38m / 8'

1

1.17m

  Bottom frame125,135,150,170,190(230mm top space to frame)

TypeB

2.98m / 10'

1

1.17m

Bottom frame125,135,150,170,190(230mm top space to frame)

Type C

3.58m / 12'

1

1.17m

Bottom frame125,135,150,170,190(230mm top space to frame)

Type D

4.18m / 14'

2

1.17m

Bottom frame125,135,150,170,190(230mm top space to frame)

Type E

4.78m / 16'

3

1.17m

 Bottom frame125,135,150,170,190(230mm top space to frame)

Gate hook is 12mm diameter steel

Chain and ring are 4mm steel

Chain length; 200mm

325g

lug Hight:40-50mm

Thickness:5mm

Standard weight

Steel diameter; 20mm

Threaded length; 275mm

8mm diameter hole

 950g

Steel diameter; 20mm

Threaded length; 275mm

1.2kg
