2mm 80 20 Nickel Chrome High Resistance Wire N6 Steel Alloy Cr20Ni80 Copper Wire For Heater Ni80
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Cr 20% Ni 80% Nichrome 80/20Stablohm 650 Carbon Fiber Heating Ni80Cr20 Bright And Soft Alloy Wire
-
Resistance Alloy Spark Resistance Wire Spiral Heating Resistance Wire Fecral Coil
-
Fecral Heat Resistant Flat Wire Electric Alchrome 875 Alloy 837 Resistance Heating Alloy Wire
-
Cr20Ni80 Nichrome Alloy C Nickel Alloy Plate Nickel Chrome 70 30 Electric Resistance Nichrome Heating Wire
-
Cr25Al5 Electric Alloy Heating Resistance Wire MWS-875 Element For Blanket
-
Ni80 Roll 36G 12V Nichrome Resistance Wire Heater Nickel Chrome Heat Wire Low Voltage Alloy A
Product Description
Product Description
Ni-Cr and Ni-Cr-Fe electric heating alloys
Nichrome electric heating alloys with high and stable resistance, corrosion resistance, surface oxidation resistance is good, a better under high temperature and seismic strength, good ductility, good workability and weldability.
It is widely used in industrial electric furnace, metallurgy, household appliances, machinery manufacturing, heating element and resistor varistor other material.
| Alloy Nomenclature Performance | Cr20Ni80 | Cr30Ni70 | Cr15Ni60 | Cr20Ni35 | Cr20Ni30 | |
| Main chemical composition (%) | Ni | Rest | Rest | 55.0-61.0 | 34.0-37.0 | 30.0-34.0 |
| Cr | 20.0-23.0 | 28.0-31.0 | 15.0-18.0 | 18.0-21.0 | 18.0-21.0 | |
| Fe | ≤1.0 | ≤1.0 | Rest | Rest | Rest | |
| Max. continuous service temp. of element (ºC) | 1200 | 1250 | 1150 | 1100 | 1100 | |
| Resistivity at 20ºC (μΩ·m) | 1.09 | 1.18 | 1.12 | 1 |
1.04 |
|
| Density (g/cm3) | 8.4 | 8.1 | 8.2 | 7.9 | 7.9 | |
| Thermal conductivity (KJ/m·h·ºC) | 60.3 | 45.2 | 45.2 | 43.8 | 43.8 | |
| Coefficient of lines expansion (α×10-6/ºC) | 18 | 17 | 17 | 19 | 19 | |
| Melting point (approx.) (ºC) | 1400 | 1380 | 1390 | 1390 | 1390 | |
| Elongation at rupture (%) | >20 | >20 | >20 | >20 | >20 | |
| Micrographic structure | austenite | austenite | austenite | austenite | austenite | |
| Magnetic properties | nonmagnetic | nonmagnetic | Weak magnetic | Weak magnetic | Weak magnetic | |
Round wire: diameter 0.03mm-10.0mm
Flat wire: thickness 0.2mm-1.0mm, width 0.08mm-40.0mm
Related Products
