Home > Products > PMF50 square photoelectric sensor > Retro-Reflective Photo Sensor With 7m Distance for Mine Doors
Retro-Reflective Photo Sensor With 7m Distance for Mine Doors
- tianjin
- T/T PayPal
- 7 days
You May Like
-
Mirror Reflector Optic Sensor for Commercial Roll up Garage Door
-
Infrared Retro-Reflective Photo Sensor With 7m Distance for Mechanical Parking
-
IInfrared Retro-Reflective Optical Sensor for Car Positioning Detection
-
Infrared Photoelectric Switch for Commercial Roll up Garage Door
-
IP65 Infrared Safety Beam Retro-Reflective Photo Sensor Exporters
-
Relay Output Infrared Retro-Reflective Photo Sensor for High-Performance Cleanroom Doors
Product Details
| Brand Name | G-TEK | Place of Origin | China | |
| Model Number | PMF50R | Usage | Other, industrial doors | |
| Theory | Optical Sensor | Output | Other, relay output |
Product Description
Product Parameters | |
Photoelectric sensor | PMF50R |
Detection type | Retro-reflective type |
Detection object | MinΦ30mm opaque object |
Detection distance | RP04: 0~7m，RP05: 0~7m |
Supply voltage | 10-30v DC |
No-load current | Max.60mA |
Response time | Max.20ms |
Light | Red LED(Wave length: 660mm) |
Action mode | Selecting Light On or Dark On by potentiometer |
Control output | Relay output，(contact rating: 30VDC 1A resistance load， 120VAC，1A resistance load，contact component: 1C)
|
Indicator | Power indicator: green；Action indicator: red |
Protection circuit | Reverse polarity protection |
Ambient brightness | Sunlight: Max.30000Lux fluorescent: Max.3000Lux |
Ambient temperature | －20℃~65℃ (No-freezing) |
Ambient humidity | 0~90%RH |
Housing material | Housing: ABS Lens: PMMA |
Shape and size | As dimension |
Cable | Φ5, 2×0.3mm2 |
Protection rating | IP65 (IEC) |
Accessory | Bracket: IB02，Screw: M4×25 |
