Vertical Air Supply Super Clean Workbench

1

Product Name: vertical air supply super clean workbench

Model: sw-cj-1d

Product classification: single sided according to the use function

Product structure: the humanized design fully considers the actual needs of users. According to the counterweight balanced structure, the glass sliding door of the operation window can be positioned arbitrarily, making the experiment more convenient and simple.

Product features: 1. Built in socket, easy to use electricity and simple operation. 2. 2. The quasi closed glass damper moves up and down, hovers freely, and is equipped with a convenient handle. 3. The adjustable air volume fan system is adopted, and the electrical remote control switch is used to ensure that the wind speed in the working area is always in an ideal state. 4. Open large-area uniform flow air supply. 5. The clean stainless steel table top is not easy to be corroded and rusted. 6. There is a universal wheel at the bottom to facilitate the movement of the workbench, which is easy and labor-saving. 7. Equipped with ultraviolet sterilization lamp tube and high brightness lighting lamp tube. 8. It is equipped with high efficiency air filter and primary efficiency filter for preliminary filtration, which can effectively prolong the service life of high efficiency filter. 9. The equipment adopts steel wood structure and is made of full-color steel plate, which is simple and beautiful.

Parameters:

Cleanliness level: 100 @ ≥ 0.5 μ M (209E)

Colony count: ≤ 0.5 / dish · hour（ Φ 90mm plate)

Average wind speed: (M / s)  0.25 ~ 0.45 (fast and slow two speed)

Noise: ≤ 62db (a)

Half peak value of vibration: ≤ 0.5 μ M (x, y, z direction)

Illuminance (LX): ≥ 300

Power supply: AC single-phase 220V / 50Hz

Maximum power (W): 300

Applicable number: single person / single side

Specification and quantity of high efficiency filter: 695 × four hundred and sixty × thirty-eight × ①

Specification and quantity of fluorescent lamp / UV lamp: 15W × ①/15W × ①

Working area size (mm): length * depth * height ： seven hundred × five hundred × five hundred and twenty

Overall dimension (mm) length * depth * height: 860 × five hundred and fifty × one thousand and six hundred

Weight (kg): 85

Package size: 90 * 60 * 165cm

Packing weight: 110kg
