FA 505 - Dew point sensor for OEM applications

FA 505 - Dew point sensor for OEM applications

OEM dew point sensors for residual moisture measurement in compressed air and gases

Special features for dew point sensor FA 505:

Optimized design for tight space conditions in drying systems

Measuring range -80...20°Ctd

Extremely long-term stable

Analogue output 4...20 mA or modbus-RTU interface

Condensation insensitive

Quick response time

Pressure-tight up to 350 bar (special version)

NEW: Higher resolution of the sensor signal due to improved evaluation electronics

NEW: Sensor diagnosis on site by means of hand-held instrument or CS Service Software

Measuring range

-80...20°Ctd pressure dew point resp. dew point in °Ctd0...100 %RH

-20...70 c

Other scales on request.

E.g. -60...30°Ctd ^ 4...20 mA

-50...20°Ctd ^ 4...20 mA-40...30°Ctd A 4...20 mA-20...50Ctd  4...20 mA

Accuracy:

typical ± 1°Ctd von 20...-20°Ctd

±2°Ctd von -50...-20°Ctd±3°Ctd von -50...-80 °Ctd

0699.0505-4

FA 505 dew point sensor (-20...50°Ctd) analogue output 4-20mA

o699.0505-5

FA 505 dew point sensor (-40...30°Ctd) analogue output 4-20mA

o699.0505-6

FA 505 dew point sensor (-50...20 °Ctd) analogue output 4-20mA

o699.0505-7

FA 505 dew point sensor (-60...30Ctd) analogue output 4-20mA

o699.0505-8

FA 505 dew point sensor (-80...20 °Ctd) analogue output 4-20mA

0699.0505-10

FA 505 dew point sensor (-20...50°Ctd) Modbus output

o699.0505-11

FA 505 dew point sensor (-40...30 °Ctd) Modbus output

0699.0505-12

FA 505 dew point sensor (-50...20Ctd) Modbus output

0699.0505-13

FA 505 dew point sensor (-60...30°Ctd)Modbus output

0699.0505-14

FA 505 dew point sensor (-80...20°Ctd)Modbus output

0699.3390

Standard measuring chamber for compressed air up to 16 bar

0699.3690

Measuring chamber for atmospheric dew point

cs Service Software for FA/VA sensors incl.PC connection set,

05542007

USB connection and interface adapter to the sensor

0554.0002

Control and calibration set 11.3 % RH

0554.0004

Control and calibration set 33 % RH

0554.0005

Control and calibration set 75.3 % RH

0553.5051

Connection cable for FA 505, length: 5 m

0553.5053

Connection cable for FA 505, length: 10 m

3200.0003

Precision calibration at 0 Ctd and 10 Ctd incl.ISO certificate

0699.3396

Precision calibration at -40 Ctd incl.ISO certificate
